rgVoipCodecPrefer
1.3.6.1.4.1.4684.5.4.4.6.0
read-write current
The preferred codec. (e.g., PCMU(G.711 u-law),
PCMA(G.711 A-law), G.729A, G.723.1).
INTEGER
■ pcmu(1)
■ pcma(2)
■ g729a(3)
■ g7231(4)
default = pcmu
rgVoipCodecVad
1.3.6.1.4.1.4684.5.4.4.7.0
read-write current
Enable/Disable Voice Activity Detection(VAD). INTEGER
■ on(1)
■ off(2)
rgVoipFaxT38
1.3.6.1.4.1.4684.5.4.4.8.0
read-write current
Enable/Disable T.38 fax. INTEGER
■ on(1)
■ off(2)
rgVoipFaxT38Port
1.3.6.1.4.1.4684.5.4.4.9.0
read-write current
The port number to send/receive T.38 packets. INTEGER (1..65536)
rgVoipPstnSwitchkey
1.3.6.1.4.1.4684.5.4.4.10.0
read-write current
The keys of switching from VoIP mode to PSTN mode. DisplayString (0..255)
rgVoipRtpPort
1.3.6.1.4.1.4684.5.4.4.11.0
read-write current
Specify the port number to send/receive RTP packets. port :
used by 1st RTP session port + 2: used by 2nd RTP session
INTEGER (1..65536)
rgVoipRtpTos
1.3.6.1.4.1.4684.5.4.4.12.0
read-write current
The IP TOS(type of service) of RTP packet. INTEGER (1..256)
rgVoipRxGain
1.3.6.1.4.1.4684.5.4.4.13.0
read-write current
The adjustment of receive audio gain value in dB. dB: -36 ~
+18.
INTEGER (-36..18)
rgVoipTxGain
1.3.6.1.4.1.4684.5.4.4.14.0
read-write current
The adjustment of transmit audio gain value in dB. dB: -36 ~
+18.
INTEGER (-36..18)
rgVoipSpeedDialCount
1.3.6.1.4.1.4684.5.4.4.15.1.0
read-only current
The entry count of PSTN redialing digitmap. Integer32
rgVoipDigitmapCount
1.3.6.1.4.1.4684.5.4.4.16.1.0
read-only current
The entry count of PSTN redialing digitmap. Integer32
rgCallHistoryVoipInCount
1.3.6.1.4.1.4684.5.4.5.2.0
read-only current
The incoming count of Call History entry. Counter32
Table 47 MIB Scalar Objects Table
Node / OID Description Settings
