132 A PPENDIX D: I AN-02EX SNMP MIB R EFERENCE
iAN-02EX Part Number UTSI-NJTC-200323150117
Administrator Manual
June 2005
rgVoipProtocol
1.3.6.1.4.1.4684.5.4.4.1.0
read-write current
VoIP signaling protocol. INTEGER
■ mgcp(1)
■ sip(2)
■ h323(3)
rgVoipMgcpLocalport
1.3.6.1.4.1.4684.5.4.4.2.1.0
read-write current
The local listening port of MGCP stack. INTEGER (1..65535)
rgVoipMgcpPriCallAgentAddress
1.3.6.1.4.1.4684.5.4.4.2.2.0
read-write current
The network IP address of the primary CallAgent. IpAddress
rgVoipMgcpPriCallAgentPort
1.3.6.1.4.1.4684.5.4.4.2.3.0
read-write current
The port number of the primary CallAgent. INTEGER (1..65536)
rgVoipMgcpSecCallAgentAddress
1.3.6.1.4.1.4684.5.4.4.2.4.0
read-write current
The network IP address of the secondary CallAgent. IpAddress
rgVoipMgcpSecCallAgentPort
1.3.6.1.4.1.4684.5.4.4.2.5.0
read-write current
The port number of the secondary CallAgent. INTEGER (1..65536)
rgVoipMgcpExpires
1.3.6.1.4.1.4684.5.4.4.2.6.0
read-write current
The period(in seconds) of sending keep alive message to
callagent.
Integer32
rgVoipMgcpWildRsip
1.3.6.1.4.1.4684.5.4.4.2.7.0
read-write current
Enable / Disable sending RSIP with wildcarded endpoint id. INTEGER
■ on(1)
■ off(2)
default = off
rgVoipMgcpEpIdStyle
1.3.6.1.4.1.4684.5.4.4.2.8.0
read-write current
Specify endpoint id style. INTEGER
■ aaln-IpAddr(0)
■ macAddr-IpAddr(1)
■ aaln-MacAddr(2)
■ aaln-DomainName(3)
rgVoipSipLocalport
1.3.6.1.4.1.4684.5.4.4.3.1.0
read-write current
The local listening port of SIP stack. INTEGER (1..65536)
rgVoipSipProxyAddress
1.3.6.1.4.1.4684.5.4.4.3.2.0
read-write current
The network IP addresss of SIP proxy. IpAddress
Table 47 MIB Scalar Objects Table
Node / OID Description Settings
