Administrator Manual
D
I AN-02EX SNMP MIB R EFERENCE
MIB Scalar Objects as defined in UTSI-VOIPRG-MIB.mib are listed below.
Note: Please contact your UTStarcom, Inc Network Consultant or Sales
representative for the UTSI-VOIPRG-MIB.mib file.
MIB Scalar Objects
Table 47 MIB Scalar Objects Table
Node / OID Description Settings
System Status
1.3.6.1.4.1.4684.1.1.0
read-only current
The device status. It will be queried by SNMP platform. INTEGER
■ normal(1)
■ minor(2)
■ major(3)
systemVersion
1.3.6.1.4.1.4684.1.2.0
read-only current
System software version. It will be queried by SNMP
platform for matching LCT and GW SW version.
DisplayString (0..20)
currentAlarmNum
1.3.6.1.4.1.4684.5.1.1.1.1.1.5.1.0
read-only current
The number of entries in current alarm table INTEGER
rgCommonReset
1.3.6.1.4.1.4684.5.4.1.1.0
read-write current
Reset system. Trigger(1), Normal(2). INTEGER
■ trigger(1)
■ normal(2)
rgCommonFactoryReset
1.3.6.1.4.1.4684.5.4.1.2.0
read-write current
Reset to factory default setting. Trigger(1), Normal(2). INTEGER
■ trigger(1)
■ normal(2)
rgCommonHardwareVersion
1.3.6.1.4.1.4684.5.4.1.3.0
read-only current
Hardware version. DisplayString (0..255)
rgCommonFirmwareVersion
1.3.6.1.4.1.4684.5.4.1.4.0
ead-only current
software version. DisplayString (0..255)
rgCommonBootVersion
1.3.6.1.4.1.4684.5.4.1.5.0
read-only current
Boot code version. DisplayString (0..255)
