Technical data

Default Value and Value Range 125
Part Number UTSI-NJTC-200323150117 iAN-02EX
June 2005
Administrator Manual
voip_rtp_port 13456 Valid port number
voip_rtp_qos_type 1 0: disable
1: DiffServ
2: Tos
voip_rtp_qos_tos 16 0 to 3600
voip_qos_dscp_media 184 0 to 3600
voip_qos_dscp_signal 160 0 to 3600
voip_endpoint_rxgain 0 -36 to +18 dB
voip_endpoint_txgain 0 -36 to +18 dB
voip_endpoint_ring 2000,4000 <ontime,offtime>
or
<ontime1,offtime1,ontime2,offtime2>
voip_endpoint_ring_dr6 2000,4000 <ontime,offtime>
or
<ontime1,offtime1,ontime2,offtime2>
voip_endpoint_ring_dr7 2000,4000 <ontime,offtime>
or
<ontime1,offtime1,ontime2,offtime2>
voip_endpoint_ring_dr8 2000,4000 <ontime,offtime>
or
<ontime1,offtime1,ontime2,offtime2>
voip_endpoint_ring_field 0
voip_endpoint_dialtone 1000,0,350,440 <ontime,offtime,freq1,freq2>
voip_endpoint_busytone 500,500,480,620 <ontime,offtime,freq1,freq2>
or
<ontime1,offtime1,ontime2,offtime2,freq1,freq2>
voip_endpoint_ringbacktone 2000,4000,440,480
voip_endpoint_callwaittone 300,10000,440,0 <ontime,offtime,freq1,freq2>
or
<ontime1,offtime1,ontime2,offtime2,freq1,freq2>
or
<ontime1,offtime1,ontime2,offtime2,ontime3,offtime3,fr
eq1,freq2>
voip_endpoint_callwaittone_field 0
voip_endpoint_flash0 200,800 Line1 (FXS-port1) Hook- flash range: (Enter valid
number in (ms)) for <min, max>hookflash limits.
Min: lower bound of detecting hook flash. (In
Milli-seconds)
Max: upper bound of detecting hook flash. (In
Milli-seconds)
Table 46 abconfig.cfg Default Value and Value Range
Field Default Value Valid Range
