Technical data

Part Number UTSI-NJTC-200323150117 iAN-02EX
June 2005
Administrator Manual
C
D EFAULT S ETTING & V ALUE
Default Value and
Value Range
Table 46 abconfig.cfg Default Value and Value Range
Field Default Value Valid Range
bootcode_version V1.6.7 Read-only.
device_mode 1 0: Bridge Mode
1: Gateway Mode
wan 1 0: Static IP
1: DHCP client
2: PPPoE client
wan_ip 172.25.25.1 Valid IP address
wan_mask 255.255.255.0 Valid Netmask
wan_gateway 172.25.25.1 Valid IP address
wan_dns 172.25.25.1 Valid IP address
pppoe_username 1234 A generic string with up to 32 characters.
pppoe_password 0000 A generic string with up to 32 characters.
provision_priority 0 Provision priority=0 HTTP Ist and TFTP 2nd
Provision priority=1 TFTP Ist and HTTP 2nd
Provision priority=0 HTTP only (Set TFTP
provisioning/upgrade server value=0)
Provision priority=1 TFTP only (Set HTTP
provisioning/upgrade server value=0)
provision_server_address devicecfg.private.net/devicecfg/
utstarcom/config
Valid IP address or URL
0: Disable
provision_server_port 69, 100, 200 Valid port number
0: Disable (Port not used)
provision_http_server_address devicecfg.private.net/devicecfg/
utstarcom/config
Valid IP address or URL
0: Disable
provision_http_server_port 80 Valid port number
provision_group 0 Enter any group number or name.
0: Disable
provision_expires 86400 Time in seconds
provision_server_address_backup 0 Valid IP address
