Technical data

Provisioning Process rules 115
Part Number UTSI-NJTC-200323150117 iAN-02EX
June 2005
Administrator Manual
Provision_server_port=69,100,200
Provision_http_server_address=devicecfg.private.net/devicecfg/utstarcom/c
onfig
Provision_http_server_port=80
Provision_group=0
Provision_expires=86400
Provision_server_address_backup=0
Provision_sync_check=0
Upgrade_server_address=devicecfg.private.net/firmware/utstarcom
Upgrade_server_port=69
Upgrade_http_server_address=devicecfg.private.net/firmware/utstarcom
Upgrade_http_server_port=80
Upgrade_filename=U53V004.00.00_UTSTARCOM-V1.8.2.19a.cpr
Sample Provisioning
Flow Behavior
In the default provisioning process the Provisioning/Upgrade HTTP servers
have been given priority over the Provisioning/Upgrade TFTP servers.
By default, the ATA will be using the default UTStarcom, Inc provisioning
servers.
Provisioning/Upgrade HTTP servers are enabled on port 80
Provisioning/Upgrade TFTP servers are enabled on 3 ports. They are 69, 100
and 200.
Configuration group file feature is not used during the provisioning configuration
file search.
Expiry, by default, is set to 24 hours (86400 seconds).
Sync feature has been disabled in this flow.
Firmware upgrade is done for the file defined in the upgrade_filename flag.
Provisioning Flow
1
Step1:
ATA will first check the provisioning flag set in the current configuration.
By default the ATA will look for HTTP server.
2 Step2:
