Technical data

114 A PPENDIX B: I AN-02EX P ROVISIONING M ETHODOLOGY
iAN-02EX Part Number UTSI-NJTC-200323150117
Administrator Manual
June 2005
2 Ensure that the firmware filename follows the format <board_id>-<version>.cpr.
3 Make sure that the filename version matches the actual version of the firmware.
For example: V2.8.2.19a must have the file name <board_id>- V2.8.2.19a.cpr
File naming convention
The file naming convention is expressed as follows:
Example: U53V004.00.00_UTSTARCOM-V1.8.2.Xa.cpr
<Board id>_<company>.cpr
<Board id>= U53V005.00.00
<Company>=UTSTARCOM
<.cpr>= firmware file extension.
The user will have to place this file on the Upgrade Server at the specific
location where the ATA will download this file.
Example: UTSI generic release is called V1.8.2.Xa.
Note: The GUI does not allow entry of the firmware file name, this can be
configured only by CLI or using the configuration file on the ATA.
Provisioning Default
Values
The default provisioning priority is HTTP first priority, TFTP second priority. It
has been noticed in the field that the provisioning of configuration files and
firmware is faster when using the HTTP protocol.
TFTP Address: devicecfg.private.net/devicecfg/utstarcom/config
TFTP ports 69, 100, 200
HTTP Address: devicecfg.private.net/devicecfg/utstarcom/config
HTTP port 80
TFTP upgrade Server Address: devicecfg.private.net/firmware/utstarcom
TFTP ports 69
HTTP Upgrade Server Address: devicecfg.private.net/firmware/utstarcom
HTTP port 80
UTStarcom,
Provisioning Default
Flag Values
Provision_priority=0
Provision_server_address=devicecfg.private.net/devicecfg/utstarcom/config
