Technical data

Provisioning Process rules 113
Part Number UTSI-NJTC-200323150117 iAN-02EX
June 2005
Administrator Manual
voip_info_user1=0
voip_jitterbufMin=0
voip_jitterbufMax=150
voip_jitterbufTarget=0
vlan_tag_priority_port0=0
vlan_tag_priority_port1=0
vlan_tag_vlan_id_port0=4
vlan_tag_vlan_id_port1=4
vlan_tag_enable=0
vlan_tag_add_port0=0
vlan_tag_add_port1=0
vlan_tag_remove_port0=0
vlan_tag_remove_port1=0
vlan_tag_replace_port0=0
vlan_tag_replace_port1=0
vlan_tag_voice_priority=1
vlan_tag_voice_vlan_id=3
Firmware Upgrade The UTStarcom iAN-02EX supports remote firmware upgrade using HTTP or
TFTP servers. The frequency of auto updates can be set using the provisioning
expiry timer.
Firmware is the main software image, which the ATA needs to perform all tasks
in real time. Firmware upgrades are required for adding new features or to
resolves bugs.
The ATA supports a mechanism to remotely access a HTTP or TFTP server and
download a new firmware image.
The ATA verifies the file name as mentioned in the .cfg file to authenticate board
id of the ATA and the firmware image. After a successful download the ATA
performs an auto reboot to bring the new firmware image into effect.
During the period of firmware upgrade three LEDs on the unit blink
simultaneously. In the event of an unsuccessful firmware download the ATA
continues to function on the old image.
In order to enable remote Firmware upgrade, the items below are essential:
1 Make sure upgrade_server_address and upgrade_filename are included in the
config file to be downloaded to the device.
