Provisioning Process rules
101
Part Number UTSI-NJTC-200323150117
iAN-02EX
June 2005
Administrator Manual
Default values=80
■
Sync Check is a feature where the SIP proxy initiates a sync check event in a
SIP message. The ATA restarts the entire provisioning process to keep in
sync with the provisioning and upgrade servers. The Authentication feature is
utilized to authenticate the requesting ATA. Currently this feature has been
disabled on the ATA's. In order to activate this feature, the SIP-Proxy should
support this feature.
Note: Factory shipped V1.8.2.2a version does not have these provisioning
features. User has to upgrade the unit to V1.8.2.19a or later version in order to
utilize these provisioning features.
Provisioning Process
rules
Auto-Configuration
The UTStarcom iAN-02EX supports remote auto configuration updates using
remote provisioing (HTTP/TFTP) server. It has the capability to access a remote
Provisioning HTTP or TFTP server and download the configuration files and
perform auto updates.
Brief description on
HTTP/TFTP Provisioning
servers
TFTP Provisioning servers
Provisioning TFTP server can be defined as either an IP-address or a URL.
User has the flexibility to disable HTTP and TFTP. This could be achieved by
putting the values as, HTTP/TFTP server=0
Port hunting feature
3 ports can be defined for TFTP servers. If timeout occurs on one port then the
ATA will hunt the remaining 2 ports as defined by the user.
During the hunting process the ATA will look for the 3 configuration files on all 3
ports.
If it finds the configuration file on one port then it will not look for this
configuration file in the remaining 2 ports. This is done in order to reduce the
total provisioning time.
If the value for a particular port is zero, then the port will not be tried.
If all configuration files/Firmware files are received during this process, the
TFTP port hunting system will not try an HTTP configuration file search.
HTTP Provisioning
servers
Provisioning HTTP server can be defined either as an IP-address or a URL.
