1 Overview OVERVIEW The iAN-02EX is a Customer Premises Equipment that enables Voice over IP. It interfaces regular POTS telephones with IP based telephony networks. It is standalone device which provides a cost effective voice communication over an existing broadband connection. The iAN-02EX is a standard's based communication devices that deliver true, next-generation voice-over-IP (VoIP) terminations to businesses and residences worldwide.
Chapter 1: Overview ■ Phone Interface: 2 FXS/POTS Interface to connect regular analogue phone ■ PSTN Interface: 1 FXO / PSTN Life line Interface (Optional) ■ Power Supply Connector Key Features of iAN-02EX: ■ IOP (Inter-Operability) with major soft-switch vendors ■ Multi-facet signaling supporting MGCP, SIP & H323 ■ SNMP based EMS for VoIP deployments ■ Supports remote software upgrades ■ Plug & Play, Auto Configuration / Auto Provisioning ■ Auto Switch to PSTN in case of power failure
System Requirements Part Number UTSI-NJTC-200323150117 June 2005 ■ One or two standard touch-tone telephone(s) ■ Subscribe to a VoIP service provider for VoIP services 19 iAN-02EX Administrator Manual
Chapter 1: Overview iAN-02EX Administrator Manual Part Number UTSI-NJTC-200323150117 June 2005
2 Panel & LEDs HARDWARE INSTALLATION Figure 2 Front Panel of 2-Port VoIP Gateway Table 3 LED LED Color Status Description PWR Green On When the 2-port VoIP Gateway is powered on Off No power supply WAN ENET VoIP LINE1 & LINE2 Green Green Green Green Blinking When data is being transmitted or received On When ADSL connection is established Off When there is no ADSL connection Blinking When data is being transmitted or received On When Ethernet connection is established Off When
Chapter 2: Hardware Installation Installation Procedure ■ ENET: Ethernet RJ-45 connector, connected to PC using a RJ-45 Ethernet cable ■ WAN: Ethernet RJ-45 connector, connected to WAN access device, such as the cable modem or ADSL modem Figure 4 Installation Diagram 1 LINE: Plug one end of the RJ-11 telephone line into the LINE port and plug the other end into the phone port of the splitter. Then connect the splitter to the phone socket in the wall using a RJ-11 telephone line.
3 TECHNICAL SPECIFICATION Table 4 Technical Specifications Item Specifications MANAGEMENT AND PROVISIONING Automatic System firmware/Configuration download via TFTP/HTTP servers Authentication based on user name, password and login ID Flexibility to use TFTP only, HTTP only or both TFTP/HTTP Configurable TFTP/ HTTP priority order selection TFTP port enable/disable, TFTP port hunting up to 3 ports Configurable TFTP/HTTP feature with enable/disable flags URL based entry for TFTP/HTTP provisioning 3 Optio
APPENDIX : TECHNICAL SPECIFICATION Table 4 Technical Specifications Item Specifications VOICE FEATURES Call hold Configurable (*, #) feature codes Call transfer with/without consultation Call Waiting and per call Call-Waiting Blocking 3 Party Conference Call forward (Always, busy, no answer) DND (Do not disturb) VoIP Speed dial Per Port VoIP Digit Map PSTN Digit Map Configurable PSTN access code Configurable Tone definition Distinctive Ring Fax Caller Number/Name display Caller ID Blocking Per Call
Table 4 Technical Specifications Item Specifications LEDs Ethernet LAN: 10/100M, Link/Activity WAN: 10/100M, Link/Activity VoIP Ready LINE1: Activity LINE2: Activity Power SUPPORTED SPECIFICATION AND APPLICATIONS DATA NETWORKING ARP Address Resolution Protocol MAC Address (IEEE 802.
APPENDIX : TECHNICAL SPECIFICATION Table 4 Technical Specifications Item Specifications VOICE ALGORITHMS G.711 (A-law or mLaw), G.723.1 (6.3 kbps, 5.3 kbps) G.726 (16/24/32/40 kbps), G.729 a/b Line Echo Cancellation [32ms (min) ~ 128ms (max)] Adaptive Jitter Buffer (Up to 90ms jitter) Asymmetrical Codes (Allows upstream and downstream to use different codecs) AGC (Auto Gain Control), AEC (Auto Echo Cancellation) Voice Activity Detection (VAD) and Comfort Noise (CNG) Echo Cancellation G.165/G.
4 CONFIGURING TCP/IP PROTOCOL The iAN-02EX ATA has two modes of operation to communicate from a PC to the iAN-02EX ATA: ■ Gateway Mode ■ Bridge Mode The factory default mode is Gateway mode. After the PC is properly configured, the ATA can be accessed with the procedures listed in Web Browser. Gateway Mode To communicate and configure iAN-02EX, the PC on your LAN must install TCP/IP protocol.
Chapter 4: Configuring TCP/IP Protocol Figure 5 Settings - Network Connections - Gateway Mode 2 Right click Local Area Connection and select Properties. Figure 6 Local Area Connection - Properties - Gateway Mode 3 Select Internet Protocol (TCP/IP) and then click Properties in Figure 7.
Gateway Mode 29 Figure 7 Local Area Connection Properties - Gateway Mode 4 Select the radio button for Obtain an IP address automatically in Figure 8 and click OK to return to Figure 7. Click OK to exit.
Chapter 4: Configuring TCP/IP Protocol Figure 8 Internet Protocol (TCP/IP) Properties - Gateway Mode The Configuration for Windows 2000/XP is now completed. Refer toWeb Browser for configuration procedures via web browser. Bridge Mode To communicate and configure iAN-02EX, the PC on your LAN must install TCP/IP protocol. Make sure that the PC is configured with static IP address of 172.25.25.100 and is connected to the ENET (Ethernet) port of the ATA. Ensure that the WAN port is not connected.
Bridge Mode 31 Note: the ISP normally has to provide 2 IP addresses, one for the ATA and one for the PC connected to the LAN port. Following the procedures below to configure TCP/IP protocol for Windows 2000 or Windows XP operating system. 1 From the Start menu, click Settings and then select Network Connections. Figure 9 Settings - Network Connections - Bridge Mode 2 Right click Local Area Connection and select Properties.
Chapter 4: Configuring TCP/IP Protocol Figure 10 Local Area Connection - Properties - Bridge Mode 3 Select Internet Protocol (TCP/IP) and then click Properties in Figure 11.
Web Browser 33 4 Select the radio button for Using the following IP address in Figure 12. Set IP address as 172.25.25.100 and set Subnet mask as 255.255.255.0. Click OK to confirm the settings and return to Figure 11. Click OK again to exit. Figure 12 Internet Protocol (TCP/IP) Properties - Bridge Mode The Configuration for Windows 2000/XP is now completed. Refer to Web Browser for configuration procedures via web browser.
Chapter 4: Configuring TCP/IP Protocol Figure 13 Starting Web Browser Window - Gateway Mode 3 Figure 14 prompts for user name and password. The web configuration menu provides two operation modes: user mode and supervisor mode. For user mode, enter the predefined user name as user and password as 12345. For the supervisor mode, enter the predefined user name as supervisor and password as utstar. Click OK to access the configuration as shown in Figure 15.
Web Browser 35 Figure 15 Web Configuration Main Menu - Gateway Mode Refer to Chapter 5 - Configuration for more details of web configuration operations.
Chapter 4: Configuring TCP/IP Protocol iAN-02EX Administrator Manual Part Number UTSI-NJTC-200323150117 June 2005
5 CONFIGURATION iAN-02EX Gateway implements a Web server allowing user configure this device via the Web interface. This Interface provides comprehensive system management scheme, including system configuration, performance monitoring, system maintenance and administration. Refer to Table 5 for the features and functions available to "Supervisor" vs. "User" privileges.
Chapter 5: Configuration Table 5 Feature Lists Features Functions VoIP Protocol V MGCP V User V SIP V Audio Config V RTP V Tone V FAX V STUN V Speed Dial Password User Level V Supervisor Level V Call Features V Digit Map V Hook Flash V Jitter Buffer V Supervisor Password V User Password V V Upgrade Firmware V Configuration V View Configuration V Save Save Configuration Reboot V V Load Default Settings V Load Default Settings using FXS Ports V Loa
Configuring via Web Browser 39 Figure 16 Starting Web Browser Window - Gateway Mode 3 Figure 17 prompts for user name and password. The web configuration menu provides two operation modes: user mode and supervisor mode. For user mode, enter the predefined user name as user with password as 12345. For the supervisor mode, enter the predefined user name as supervisor with password as utstar. Click OK to access the configuration as shown in Figure 18.
Chapter 5: Configuration Figure 18 Web Configuration Main Menu - Gateway Mode Note: Click OK on any page to apply the modification. Navigating to another page without clicking OK does not save any modifications and the configuration are ignored. After making all necessary settings, you MUST Save the configurations and then Reboot for the new settings to take effect. Refer to Save and Reboot for more information.
Status 41 Figure 19 Status - System Status Table 6 Status - System Status Field Description Field Description Board ID The ID number of this module Firmware Version The current firmware version number Web GUI Version The current Web UI version number MAC Address The unique hardware number of this module VoIP Service Status The current VoIP connection status Value range: Connected to VoIP / Not Connected to VoIP. WAN Status Click WAN Status in the Status section.
Chapter 5: Configuration Table 7 Status - WAN Status Field Description Field Description WAN IP Address The IP address of the WAN WAN Subnet Mask The subnet mask of the WAN Default Gateway The gateway address of the WAN Note: The parameters contain meaningful data only when static IP address scheme is used for WAN connection. All parameters are 0 or null when static IP is not used. Refer to WAN IP for WAN connection mode configuration. DHCPC Status Click DHCPC Status in the Status section.
PPPoE PPPoE Status 43 Click PPPoE Status in the Status section. Figure 22 prompts for current PPPoE status. Refer to Table 9 for more information of the parameters.
Chapter 5: Configuration Figure 23 PPPoE - PPPoE Table 10 PPPoE - PPPoE Field Description Field Description Username User name for PPPoE registration recognized by the Internet service provider Password Password for PPPoE registration recognized by the Internet service provider Configure the parameters accordingly. Click OK to confirm the modification or click Cancel to discard the modification. Save the configuration and Reboot the module for the new configuration to take effect.
WAN 45 Figure 24 WAN - WAN IP Table 11 WAN - WAN IP Field Description Field Description Static IP Address To configure a static IP address. IP The static IP address of the iAN-02EX VoIP gateway Default: 171.25.25.1 Mask The subnet mask of the iAN-02EX VoIP gateway Default: 255.255.255.0 Gateway The network gateway address of the iAN-02EX VoIP gateway Default: 172.25.25.1 DNS 1 The IP address of domain name server 1. DNS 2 The IP address of domain name server 2. Default: 192.168.100.
Chapter 5: Configuration Save the configuration and Reboot the module for the new configuration to take effect. Note: Refer to DHCPC Status for PPPoE status. Device Mode iAN-02EX has two operational modes: Bridge mode and Gateway mode. With bridge mode, iAN-02EX acts as a transparent bridge to pass traffic between the module and an end-user device. The WAN port and the LAN (ENET) port share the same IP address.
DOS 47 Figure 26 WAN - MTU Rate Table 13 WAN - MTU Rate Field Description Field Description MTU Rate Specify the network MTU rate Default: 1460 Configure the parameters accordingly. Click OK to confirm the modification or click Cancel to discard the modification. Save the configuration and Reboot the module for the new configuration to take effect. DOS DOS (Denial of service) provides access control for RTP packets, web/telnet provisioning, etc.
Chapter 5: Configuration Table 14 DOS - Denial of Service Field Description Item Description RTP Source Check Enable / disable RTP source checking. When enabled, RTP packets with source ip/port not presented in remote SDP are dropped. Ping Reply Enable / disable ping reply to ICMP request Web Provisioning Enable / disable web provisioning from WAN side. For Gateway mode only. Telnet Provisioning Enable / disable telnet provisioning from WAN side. For Gateway mode only.
Gateway Mode Settings 49 Figure 28 NTP - NTP Table 15 NTP - NTP Field Description Item Description NTP Server The IP address of the network time protocol server. Expires The period that the VoIP gateway retrieves time from NTP server. Default: 86400 seconds Time Zone The time difference between the local time and GMT. Default: -5 Configure the parameters accordingly. Click OK to confirm the modification or click Cancel to discard the modification.
Chapter 5: Configuration LAN Configuration When the module operates in the Gateway mode, it supports the NAT (NAPT) feature. It means the WAN and LAN interfaces are located in different network segments and therefore the data traffic needs to be routed between the two interfaces. To properly communicate with iAN-02EX, an IP address must also be assigned to the LAN port of the user's PC.
Gateway Mode Settings 51 Table 16 Gateway Mode Settings - LAN Configuration Field Description Item Description LAN IP Configuration LAN IP The LAN IP address Default: 172.25.25.1 LAN Netmask The LAN netmask Default: 255.255.255.0 LAN Gateway The LAN gateway IP address. Default: 172.25.25.1 DHCP Configuration Status To enable/disable DHCP server's dynamic IP address assignment. Default: Enable Mode To automatically obtain or manually assign the DNS server address.
Chapter 5: Configuration Click Port Forwarding in the Gateway Mode Settings section. Figure 30 prompts for configuration. Refer to Table 17 for more information of the parameters.
Gateway Mode Settings 53 Enter the corresponding ID number listed in the table and click Delete to remove the entry. Save the configuration and Reboot the module for the new configuration to take effect. Note: Rule ID # 10 is a module default entry. Do not delete this entry. IP Filter iAN-02EX provides the option to block access from the IP addresses specified in the IP filter. Click IP Filter in the Gateway Mode Settings section. Figure 31 prompts for configuration.
Chapter 5: Configuration Enter the corresponding ID number listed in the table and click Delete to remove the entry. Save the configuration and Reboot the module for the new configuration to take effect. DMZ DMZ (De-Militarized Zone) is a firewall feature governing real-time information exchanged through the VOIP gateway device. DMZ allows a single computer on the LAN side network to expose all of its ports to the Internet, which means the exposed computer is no longer behind the firewall.
QoS QoS Configuration ■ DSCP ■ VLan Tag 55 iAN-02EX supports the function of attaching ToS (Type of Service) or DSCP (Differentiated Services Code Point) information on outgoing packets so these packets may be processed with higher priority. Click QoS Configuration in the QoS section. Figure 33 prompts for configuration. Refer to Table 20 for more information of the parameters.
Chapter 5: Configuration Save the configuration and Reboot the module for the new configuration to take effect. DSCP iAN-02EX provides the option to retain or remove the outgoing packet priority for ToS. Click DSCP in the QoS section. Figure 34 prompts for configuration. Refer to Table 21 for more information of the parameters. Figure 34 QoS - DSCP Table 21 QoS - DSCP Field Description Field Description Trusted Retain the DSCP priority associated with outgoing packets. Default.
Mac Cloning 57 Figure 35 QoS - VLan Tag Table 22 QoS - VLan Tag Field Description Field Description VLan Tag To disable/enable VLan tag Default: Disable Data Priority The priority value for data packet Default: 0 Data VLan ID The data VLan ID Default: 4 Voice Priority The priority value for voice packet Default: 1 Voice VLan ID The voice VLan ID Default: 3 Configure the parameters accordingly. Click OK to confirm the modification or click Cancel to discard the modification.
Chapter 5: Configuration Figure 36 Mac Cloning - Mac Cloning Table 23 Mac Cloning - Mac Cloning Field Description Field Description Mac Cloning To disable/enable MAC cloning Default: Disable Mac Address The Mac address to be assigned to the WAN. Default: 000000000000 Configure the parameters accordingly. Click OK to confirm the modification or click Cancel to discard the modification. Save the configuration and Reboot the module for the new configuration to take effect.
PSTN 59 Figure 37 PSTN - Switch Key Table 24 PSTN - Switch Key Field Description Field Description Pstnswkey The PSTN switch key for swathing from VoIP mode to PSTN mode. Default: 0000 Configure the parameters accordingly. Click OK to confirm the modification or click Cancel to discard the modification. Save the configuration and Reboot the module for the new configuration to take effect. Digit Map This function allows the users to set PSTN digit map.
Chapter 5: Configuration Figure 38 PSTN - Digit Map Table 25 PSTN - Digit Map Field Description Item Description PSTN Digitmap Prefix Enter the prefix of the telephone number to be added/modified/deleted Length Enter the total length of the telephone number. The length is ranged from 0~64. "0" means the length is not fixed. Digit Map Table No. The digit map ID number. Prefix The prefix of the telephone number. Length The length of the telephone number.
Provision 61 and the existing local setting. If the downloaded setting parameter is newer, then it will overwrite the existing local setting parameters. Provision Click Provision in the Provision section. Figure 39 prompts for configuration. Refer to Table 26 for more information of the parameters. Figure 39 Provision - Provision Table 26 Provision - Provision Field Description Item Description Provision Priority The priority of the provision server.
Chapter 5: Configuration Table 26 Provision - Provision Field Description Item Description HTTP Server Address The IP address or URL of the HTTP provision server. Default: devicecfg.private.net/devicecfg/utstarcom/config HTTP Server Port The port numbers of the HTTP provision server. Group The group the VoIP gateway belongs to. The maximum length is 64. Default: 80 Default: 0 Expires The period (in seconds) that the VoIP gateway retrieves configuration files from Provision server.
Element Management System (EMS) 63 Figure 40 Syslog - Syslog Table 27 Syslog - Syslog Field Description Item Description Server Address The IP address of syslog server. Default: 0, disable syslog server Server Port The port number of syslog server. Default: 514 Level-3/Level-4 Debug Disable / enable sending level-3/level-4 debug messages to syslog server Default: Disable Configure the parameters accordingly. Click OK to confirm the modification or click Cancel to discard the modification.
Chapter 5: Configuration Figure 41 EMS - EMS Table 28 EMS - EMS Field Description Item Description Server Address The IP Address of the EMS server 0: Disable syslog server Server Port The port number of the EMS server Default: 63030 Community The community used by the EMS server Value range: Public community / Private community Default: private Expires The period that the VoIP Gateway sends keeping-alive message to EMS server.
Element Management System (EMS) 65 Figure 42 EMS - SNMP Community Table 29 EMS - SNMP Community Field Description Item Description Set Community The community for the set function on EMS. Get Community The community for the get function on EMS. Trap Community The Community used when the user processes the traps. Default: private Default: public Default: public Configure the parameters accordingly. Click OK to confirm the modification or click Cancel to discard the modification.
Chapter 5: Configuration Figure 43 EMS - SNMP Community Table 30 EMS - SNMP Trap Target Field Description Field Description Trap Disable / enable SNMP trap Default: Off Target 1~ 4 Specify the IP address to which the traps of the VOIP Port 1~ 4 Specify the Port to which the traps of the VOIP Gateway will be sent Configure the parameters accordingly. Click OK to confirm the modification or click Cancel to discard the modification.
VoIP Protocol ■ Speed Dial ■ Call Features ■ Digit Map ■ Hook Flash ■ Jitter Buffer 67 Click Protocol in the VoIP section. Figure 44 prompts for configuration. Refer to Table 31 for more information of the parameters. Figure 44 VoIP - Protocol Table 31 VoIP - Protocol Field Description Field Description MGCP MGCP voice signaling protocol SIP SIP voice signaling protocol Default. Configure the parameters accordingly.
Chapter 5: Configuration Figure 45 VoIP - MGCP Table 32 VoIP - MGCP Field Description Item Description Local Port This port number to receive/send data from/to the call agent. Default: 2427 Call Agent Address The IP address of call agent. Default: 127.0.0.1 Call Agent Port This port number to receive/send data from/to the VoIP gateway.
VoIP 69 Save the configuration and Reboot the module for the new configuration to take effect. Note: Refer to Protocol for disable/enable MGCP mode. User Click User in the VoIP section. Figure 46 prompts for configuration. Refer to Table 33 for more information of the parameters.
Chapter 5: Configuration Figure 47 VoIP - SIP Table 34 VoIP - SIP Field Description Item Description Local Port The port number of the SIP stack. Default: 5060 Proxy Address The IP address of SIP proxy Proxy Port The port number used by SIP Proxy Default: 0, disable Default: 5060 Registrar Address The IP Address of Registration server. Registration Server is often the same as SIP Proxy Server. Registrar Port The port number of Registration server.
VoIP 71 Table 34 VoIP - SIP Field Description Item Description Outbound Proxy Port Specifies the port number of SIP Proxy server. Generally the default is 5060. Expires The period (in seconds) that the VoIP Gateway sends keeping-alive message to Registration server. This is to check the connection status in case the VoIP Gateway is accidentally disconnected from the Registration server. Default: 3600 SIP Domain The domain name for the URL to be registered.
Chapter 5: Configuration Figure 48 VoIP - Audio Config Table 35 VoIP - Audio Config Field Description Item Description Port Index Port 1 / Port 2 Codec Rate The period (in milliseconds) that the VoIP Gateway sends voice packets to call party. This value must be a multiple of 10. Default: 20 Preferred Codec The preferred method of voice compression on per port basis. Default: G.729A VAD (Voice Activity Detection) Enable: sending packets only while the user is speaking.
VoIP 73 Save the configuration and Reboot the module for the new configuration to take effect. RTP Click RTP in the VoIP section. Figure 49 prompts for configuration. Refer to Table 36 for more information of the parameters. Figure 49 VoIP - RTP Table 36 VoIP - RTP Field Description Item Description RTP Port RTP port number Default: 13456 Configure the parameters accordingly. Click OK to confirm the modification or click Cancel to discard the modification.
Chapter 5: Configuration Figure 50 VoIP - Tone Table 37 VoIP - Tone Field Description Item Country Tones Description Custom Specific Tone North America Rx Gain (dB) Adjusts the receiving audio gain to be higher or lower. Default: 0 Tx Gain (dB) Adjusts the transmitting audio gain to be higher or lower.
VoIP 75 Table 37 VoIP - Tone Field Description Item Description Ring The ringing cadence. Select the tone from the drop down box for DR1 to DR8. DR1 to DR5 are preconfigured and DR6 to DR8 can be modified. Dial Tone ■ DR1 <2000, 4000> ■ DR2 <800, 400, 800, 4000> ■ DR3 <400, 200, 400, 200, 800, 4000> ■ DR4 <300, 200, 1000, 200, 300, 4000> ■ DR5 <500, 500> ■ DR6 <2000, 4000> ■ DR7 <2000, 4000> ■ DR8 <2000, 4000> The dialing tone pattern.
Chapter 5: Configuration Save the configuration and Reboot the module for the new configuration to take effect. FAX Click Fax in the VoIP section. Figure 51 prompts for configuration. Refer to Table 38 for more information of the parameters. Figure 51 VoIP - Fax Table 38 VoIP - FAX Field Description Item Description T.38 Fax Enable/disable data-resending mechanism in case of any missing data during transmission Default: Enable T.38 Port The port number for for sending/receiving T.
VoIP 77 Figure 52 VoIP - Stun Table 39 VoIP - STUN Field Description Item Description NAT Address The IP address of NAT firewall. Default: 0 Stun Server Address The IP address of STUN (Simple Traversal of User Datagram) server. Default: 0 Stun Server Port The port number of STUN server. Default: 3478 Local Port The local port number of STUN client. Default: 3478 Expires The period that the VoIP Gateway sends STUN message to STUN server.
Chapter 5: Configuration Click Speed Dial in the VoIP section. Figure 53 prompts for configuration. Refer to Table 40 for more information of the parameters. Figure 53 VoIP - Speed Dial Table 40 VoIP - Speed Dial Field Description Item Description VoIP Speed Dial Number The speed dial number of the call party. Destination The SIP address or PSTN number of the called party Speed Dial Table No. The ID number for a speed dial entry Number The assigned speed dial number for a called party.
VoIP 79 Figure 54 VoIP - Call Feature Table 41 VoIP - Call Feature Field Description Field Description Port Index Port 1 or Port 2 General Feature Code Disconnect Code Call Hold Enable/disable the Call Hold feature. This must be supported by the Call Agent.
Chapter 5: Configuration Table 41 VoIP - Call Feature Field Description Field Description Call Waiting Enable/disable the Call waiting tone Per Call Deactivate: disactivate call waiting for 1 call Call Transfer (CT) Without Consultation CT to another station without prior talking to the receiving station by pressing flash and then dialing the Feature Code and the end station number With Consultation CT to another station with prior talking to the receiving station by pressing flash and then dia
VoIP Digit Map 81 In contrast to the PSTN digit map, the VOIP digit map allows VOIP calls made with leading digits and length matching the rules specified to be dialed out immediately. Click Digit Map in the VoIP section. Figure 55 prompts for configuration. Refer to Table 42 for more information of the parameters.
Chapter 5: Configuration Configure the parameters accordingly and click Add o create a new entry. Select an entry in the Digit Map Rule table and modify the parameters accordingly. Click Modify to confirm the modification. Select an entry in the Digit Map Rule table and click Delete to remove the entry. Configure Send # and click OK to confirm the modification. Save the configuration and Reboot the module for the new configuration to take effect. Hook Flash Click Hook Flash in the VoIP section.
Password Jitter Buffer 83 Click Jitter Buffer in the VoIP section. Figure 57 prompts for configuration. Refer to Table 44 for more information of the parameters.
Chapter 5: Configuration Figure 58 Password - Supervisor Password Configure the parameters accordingly. Click OK to confirm the modification or click Cancel to discard the modification. Figure 59 prompts for modification confirmation. Figure 59 Password - Supervisor Password - Confirmation Click OK in Figure 59 and the system requires the user to re-login with the new supervisor password as shown in Figure 60. Enter the new password and click OK to login.
Password 85 Figure 60 Password - Supervisor Password - Re-login Save the configuration and Reboot the module for the new configuration to take effect. Note: The password will be used for authentication. It is strongly recommended that the user resets the default password for administrative security. Note: The default supervisor password is utstar. User Password Click User Password in the Password section. Figure 61 prompts for configuration.
Chapter 5: Configuration Configure the parameters accordingly. Click OK to confirm the modification or click Cancel to discard the modification. Figure 62 prompts for modification confirmation. Figure 62 Password - User Password - Confirmation Click OK in Figure 62. If currently the ATA is in user mode, the system requires the user to re-login with the new user password as shown in Figure 63. Enter the new password and click OK to login.
Upgrade Upgrade 87 The Upgrade configuration contains the following sections: Firmware ■ Firmware ■ Configuration This feature allows the user to upgrade the firmware on the iAN-02EX VoIP Gateway from the web browser. The firmware on the iAN-02EX VoIP Gateway is stored on FLASH ROM. Download the new firmware to the local machine. Click Firmware in the Upgrade section. Figure 64 prompts for configuration.
Chapter 5: Configuration Figure 65 Upgrade - Configuration Click Confirm in Figure 66 to confirm the upgrade or Cancel to cancel. Figure 66 Upgrade - Configuration File - Apply After the upgrade is completed, Reboot the module for the new configuration to take effect. Note: Do not power off the unit during the upgrade process.
View View 89 The abconfig.cfg contains all the configuration information of the ATA. User can modify the configuration with the Configuration Click Configuration in the View section. Click the configuration file listed in Figure 67 to display the details shown in Figure 68. Figure 67 View - Configuration Figure 68 View - Configuration - abconfig.cfg Right click abconfig.cfg in Figure 67 and click Save Target As to backup the configuration file to a local directory.
Chapter 5: Configuration Figure 69 View - Configuration - abconfig.cfg.txt Save The Save configuration contains the following sections: Save Configuration ■ Save Configuration ■ Load Default Settings ■ Load Default Settings using FXS Ports ■ Load Default Keypad Whenever there's new configuration or modification, the user MUST save the new configuration data and then restart the device for the new settings to take effect. Click Save Configuration in the Save section.
Save 91 Note: Do not power off the unit during the save process. Load Default Settings Click Load Default Settings in the Save section. Figure 71 prompts for configuration. Refer to Table 45 for more information of the parameters.
Chapter 5: Configuration From the ATA simply dial *#322867973738. The ATA will restore the default settings and reboot automatically. This access is pre-configured on the ATA and cannot be changed. After reboot, the ATA will restore the default values. This is useful in the event of the service operator is unable to telnet or access the Web-base management of the ATA. This feature is available even if network is not available on the ATA.
Reboot 93 Click Reboot to restart the system and update the configuration data stored in the FLASH Memory. Note: Do not power off the unit during the reboot process.
Chapter 5: Configuration iAN-02EX Administrator Manual Part Number UTSI-NJTC-200323150117 June 2005
A TROUBLESHOOTING This section provides possible problems that may be encountered while using the iAN-02EX VoIP Gateway and suggested solutions to them. If you follow the suggested solutions below but the iAN-02EX VoIP Gateway still does not work properly, contact technical support for further advice. Q: Power LED does not light up. ■ S: First check the AC adapter rating. The input rating must meet the specification of the country. The AC adapter must be DC 10V/1.2A output.
APPENDIX A: TROUBLESHOOTING Q: Cannot use PSTN backup line. iAN-02EX Administrator Manual ■ S: Disconnect the VoIP Gateway from the power supply and then check if PSTN backup line is workable. ■ S: Check the settings of "PSTN switch key and digit map" are correct.
B Provisioning overview IAN-02EX PROVISIONING METHODOLOGY UTStarcom iAN-02EX supports extensive device provisioning mechanisms. This includes firmware upgrade and configuring parameters modification on the device. The devices are generally provisioned independently using the following methods. a Using the HTTP/TFTP provisioning/Upgrade server via the WAN side access connection of ATA towards the network.
APPENDIX B: IAN-02EX PROVISIONING METHODOLOGY Typical provisioning/upgrade scenario is as shown in Figure 74. Figure 74 Provisioning / Upgrade Scenario In this mechanism, the device configuration/firmware can be defined on a centralized server called the Provisioning/Upgrade server (Refer section 3). This configuration/firmware can be downloaded to the device manually or can be fetched from the device periodically. The device configuration can be defined in a flat file format (Refer section 3.8.4.
Provisioning Features Provisioning Features 99 The UTStarcom iAN-02EX supports two main features in its design. a Remote Configuration - Auto upgrade of ATA (Analog Telephone Adapter) configuration using remote Provisioning server and configuration files. b Remote Firmware Upgrade - Auto upgrade of ATA firmware using remote Upgrade Server and firmware file. The Provisioning and Upgrade servers can use both TFTP/HTTP protocol in order to transact the configuration and firmware files to the ATA.
APPENDIX B: IAN-02EX PROVISIONING METHODOLOGY Following are the default values used for provisioning/upgrade server. ■ Provisioning priority defines the provisioning/upgrade server priority example HTTP protocol first, TFTP protocol second. Default value=0 [HTTP first and TFTP second] ■ Provisioning TFTP Server Address is set to default UTStarcom provisioning server. This server is used for transacting all configuration files using TFTP protocol. Default values=devicecfg.private.
Provisioning Process rules 101 Default values=80 ■ Sync Check is a feature where the SIP proxy initiates a sync check event in a SIP message. The ATA restarts the entire provisioning process to keep in sync with the provisioning and upgrade servers. The Authentication feature is utilized to authenticate the requesting ATA. Currently this feature has been disabled on the ATA's. In order to activate this feature, the SIP-Proxy should support this feature. Note: Factory shipped V1.8.2.
APPENDIX B: IAN-02EX PROVISIONING METHODOLOGY HTTP will have only one port e.g. port 80 or 8080. If the value for this particular port is zero, then the port will not be tried and the HTTP process will not occur. User has the flexibility to disable TFTP and only enable HTTP. This could be achieved by putting the value as, TFTP server=0 If all configuration files/Firmware files are received during this process, then the HTTP port hunting system will not try a TFTP configuration file search.
Provisioning Process rules 103 The iAN-02EX ATA supports three types of Configuration files: ■ General Configuration File: This is used to configure all the general parameters of the ATA. ■ Group Configuration File: This is used to configure the parameters that are similar to a specific group of ATAs. The GUI interface of the ATA has a field to set the group to which the ATA belongs and then the ATA can download the group specific configuration from the group specific cfg file.
APPENDIX B: IAN-02EX PROVISIONING METHODOLOGY Group Configuration File The Group file contains the group information for a set of ATA's. It is represented as: U53V005.00.00_UTSTARCOM- ISELIN.CFG. File format is as follows: _-.cfg = U53V005.00.00 =UTSTARCOM =Group Example: U53V005.00.00_UTSTARCOM-ISELIN.CFG This file should include the settings that are common to a specific group of users.
Provisioning Process rules 105 Please note that this file needs to be encrypted before putting it on the provisioning server. UTStarcom provides an encryption engine (crypt.exe). The encryption key is the MAC address of the specified device. This program is available for lab testing only as it is limited to encrypting one file at a time. After encryption the file name changes from .cfg to .enc. Rename this file as a CFG file. Encryption Engine UTStarcom supplies the MD5 based encryption engine "Crypt.
APPENDIX B: IAN-02EX PROVISIONING METHODOLOGY wan_ip=172.25.25.1 wan_mask=255.255.255.0 wan_gateway=172.25.25.1 wan_dns=192.168.100.1 wan_dns3=0.0.0.0 pppoe_username=1234 pppoe_password=0000 provision_priority=0 provision_server_address=devicecfg.private.net/devicec fg/utstarcom/config provision_server_port=69,100,200 provision_http_server_address=devicecfg.private.
Provisioning Process rules 107 dhcp_mode=auto dhcp_df_gw=172.25.25.1 dhcp_dns=172.25.25.1 dhcp_dns2=0.0.0.0 dhcp_hostname=0 dhcp_wins=172.25.25.1 dhcp_domain=.com dhcp_lease_time=86400 dhcp_resrv_ip=192.168.100.100 dhcp_resrv_mac=00-00-00-00-00-00 dos_rtp_check=1 dos_ping_reply=1 dos_http_serv_enable=1 dos_telnet_serv_enable=1 ems_server_address=0 ems_server_port=63030 ems_community=private ems_expires=3600 factoryreset=*#322867973738 lan_ip=172.25.25.1 lan_mask=255.255.255.0 lan_gateway=172.25.25.
APPENDIX B: IAN-02EX PROVISIONING METHODOLOGY port_forward_3=tcp,0.0.0.0,0 port_forward_4=tcp,0.0.0.0,0 port_forward_5=tcp,0.0.0.0,0 port_forward_6=tcp,0.0.0.0,0 port_forward_7=tcp,0.0.0.0,0 port_forward_8=tcp,0.0.0.0,0 port_forward_9=tcp,0.0.0.0,0 port_forward_10=tcp,0.0.0.0,0 supervisor_password=utstar snmp_sendtrap=0 snmp_get=public snmp_set=private snmp_trap=public snmp_target1=0.0.0.0 snmp_target2=0.0.0.0 snmp_target3=0.0.0.0 snmp_target4=0.0.0.
Provisioning Process rules 109 voip_user_user1_password=0 voip_user_user1_displayname=0 voip_user_user1_prefix=0 voip_mgcp_localport=2427 voip_mgcp_callagent_address=127.0.0.1 voip_mgcp_callagent_port=2427 voip_mgcp_wildrsip=0 voip_mgcp_epid=domain.
APPENDIX B: IAN-02EX PROVISIONING METHODOLOGY voip_callfeature_forno_act1=*77 voip_callfeature_forno_deact1=#77 voip_callfeature_dnd_en1=0 voip_callfeature_blockclid_en1=0 voip_callfeature_blockclid_percall_act1=*67 voip_callfeature_rej_priv_en1=0 voip_callfeature_conference_en1=1 voip_callfeature_conference_code1=#92 voip_callfeature_busyredial_en1=1 voip_callfeature_busyredial_code1=#5 voip_callfeature_busyredial_repeat1=10 voip_callfeature_busyredial_stop1=60 voip_callfeature_polarity_reversal_en1=
Provisioning Process rules 111 voip_callfeature_forbusy_act2=*76 voip_callfeature_forbusy_deact2=#76 voip_callfeature_forno_act2=*77 voip_callfeature_forno_deact2=#77 voip_callfeature_dnd_en2=0 voip_callfeature_blockclid_en2=0 voip_callfeature_blockclid_percall_act2=*67 voip_callfeature_rej_priv_en2=0 voip_callfeature_conference_en2=1 voip_callfeature_conference_code2=#92 voip_callfeature_busyredial_en2=1 voip_callfeature_busyredial_code2=#5 voip_callfeature_busyredial_repeat2=10 voip_callfeature_busyredi
APPENDIX B: IAN-02EX PROVISIONING METHODOLOGY voip_codec_vad_user1=1 voip_rtp_port=13456 voip_rtp_qos_type=1 voip_rtp_qos_tos=16 voip_qos_dscp_media=184 voip_qos_dscp_signal=160 voip_endpoint_rxgain=0 voip_endpoint_txgain=0 voip_endpoint_ring=2000,4000 voip_endpoint_ring_dr6=2000,4000 voip_endpoint_ring_dr7=2000,4000 voip_endpoint_ring_dr8=2000,4000 voip_endpoint_ring_field=0 voip_endpoint_dialtone=1000,0,350,440 voip_endpoint_busytone=500,500,480,620 voip_endpoint_ringbacktone=2000,4000,440,480 voip_
Provisioning Process rules 113 voip_info_user1=0 voip_jitterbufMin=0 voip_jitterbufMax=150 voip_jitterbufTarget=0 vlan_tag_priority_port0=0 vlan_tag_priority_port1=0 vlan_tag_vlan_id_port0=4 vlan_tag_vlan_id_port1=4 vlan_tag_enable=0 vlan_tag_add_port0=0 vlan_tag_add_port1=0 vlan_tag_remove_port0=0 vlan_tag_remove_port1=0 vlan_tag_replace_port0=0 vlan_tag_replace_port1=0 vlan_tag_voice_priority=1 vlan_tag_voice_vlan_id=3 Firmware Upgrade The UTStarcom iAN-02EX supports remote firmware upgrade using HTTP
APPENDIX B: IAN-02EX PROVISIONING METHODOLOGY 2 Ensure that the firmware filename follows the format -.cpr. 3 Make sure that the filename version matches the actual version of the firmware. For example: V2.8.2.19a must have the file name - V2.8.2.19a.cpr File naming convention The file naming convention is expressed as follows: Example: U53V004.00.00_UTSTARCOM-V1.8.2.Xa.cpr _.cpr = U53V005.00.00 =UTSTARCOM <.
Provisioning Process rules 115 Provision_server_port=69,100,200 Provision_http_server_address=devicecfg.private.net/devicecfg/utstarcom/c onfig Provision_http_server_port=80 Provision_group=0 Provision_expires=86400 Provision_server_address_backup=0 Provision_sync_check=0 Upgrade_server_address=devicecfg.private.net/firmware/utstarcom Upgrade_server_port=69 Upgrade_http_server_address=devicecfg.private.net/firmware/utstarcom Upgrade_http_server_port=80 Upgrade_filename=U53V004.00.00_UTSTARCOM-V1.8.2.19a.
APPENDIX B: IAN-02EX PROVISIONING METHODOLOGY ATA will look for general, group (currently disabled) and MAC [Encrypted] configuration file from the HTTP server. If these files are received by the ATA the subsequent TFTP configuration file search is stopped. 3 Step3: Once these files are received the ATA will compare the configuration within the ATA and reboot to assume the new configuration.
C DEFAULT SETTING & VALUE Default Value and Value Range Table 46 abconfig.cfg Default Value and Value Range Field Default Value Valid Range bootcode_version V1.6.7 Read-only. device_mode 1 0: Bridge Mode wan 1 1: Gateway Mode 0: Static IP 1: DHCP client 2: PPPoE client wan_ip 172.25.25.1 Valid IP address wan_mask 255.255.255.0 Valid Netmask wan_gateway 172.25.25.1 Valid IP address wan_dns 172.25.25.1 Valid IP address pppoe_username 1234 A generic string with up to 32 characters.
APPENDIX C: DEFAULT SETTING & VALUE Table 46 abconfig.cfg Default Value and Value Range Field Default Value Valid Range upgrade_server_address devicecfg.private.net/firmware/ utstarcom Valid IP address or URL upgrade_server_port 69 Valid port number upgrade_http_server_address devicecfg.private.net/firmware/ utstarcom Valid IP address or URL upgrade_http_server_port 80 Valid port number upgrade_filename 0 A valid file with cpr extension. upgrade_provisapp_filename U53V004.00.
Default Value and Value Range 119 Table 46 abconfig.cfg Default Value and Value Range Field Default Value Valid Range dhcp_resrv_ip 192.168.100.
APPENDIX C: DEFAULT SETTING & VALUE Table 46 abconfig.cfg Default Value and Value Range Field Default Value Valid Range port_forward_6 tcp,0.0.0.0,0 Protocol, valid IP, valid Port port_forward_7 tcp,0.0.0.0,0 Protocol, valid IP, valid Port port_forward_8 tcp,0.0.0.0,0 Protocol, valid IP, valid Port port_forward_9 tcp,0.0.0.0,0 Protocol, valid IP, valid Port port_forward_10 tcp,0.0.0.
Default Value and Value Range 121 Table 46 abconfig.cfg Default Value and Value Range Field Default Value Valid Range voip_mgcp_wildrsip 0 0: Wild-carded RSIP disable 1: Wild-carded RSIP enable voip_mgcp_epid domain.net Valid domain name voip_mgcp_epidstyle 0 0: aaln/#@[ip_addr] 1: mac_addr/#@[ip_addr] 2: aaln/#@mac_addr 3: aaln/#@domain_name voip_mgcp_expires 150 Time in seconds.
APPENDIX C: DEFAULT SETTING & VALUE Table 46 abconfig.cfg Default Value and Value Range Field Default Value Valid Range voip_callfeature_forbusy_act1 *76 A "*" character followed by 2 digits number. voip_callfeature_forbusy_deact1 #76 A "#" character followed by 2 digits number. voip_callfeature_forno_act1 *77 A "*" character followed by 2 digits number. voip_callfeature_forno_deact1 #77 A "#" character followed by 2 digits number.
Default Value and Value Range 123 Table 46 abconfig.cfg Default Value and Value Range Field Default Value Valid Range voip_callfeature_forno_num2 0 A generic string with up to 50 characters. voip_callfeature_forno_en2 0 0: Disable for port 2 voip_callfeature_for_ringnum2 0 0 to 10 voip_callfeature_alertinfo_num2 0 A generic string with up to 32 characters. voip_call_second_feccode2 *25 A "*" character followed by 2 digits number.
APPENDIX C: DEFAULT SETTING & VALUE Table 46 abconfig.cfg Default Value and Value Range Field Default Value Valid Range voip_sip_registrar_address 0 Valid IP address 0: Disable voip_sip_registrar_port 5060 Valid port number voip_sip_outbound_address 0 Valid IP address 0: Disable voip_sip_outbound_port 5060 Valid port number voip_sip_expires 3600 Time in seconds voip_sip_domain 0 0: use local IP address as the domain name voip_sip_subject Call_Invite A character string.
Default Value and Value Range 125 Table 46 abconfig.
APPENDIX C: DEFAULT SETTING & VALUE Table 46 abconfig.cfg Default Value and Value Range Field Default Value Valid Range voip_endpoint_flash1 200,800 Line1 (FXS-port2) Hook-flash range: (Enter valid number in (ms)) for hookflash limits. Min: lower bound of detecting hook flash. (In Milli-seconds) Max: upper bound of detecting hook flash.
Default Value and Value Range 127 Table 46 abconfig.
APPENDIX C: DEFAULT SETTING & VALUE iAN-02EX Administrator Manual Part Number UTSI-NJTC-200323150117 June 2005
D IAN-02EX SNMP MIB REFERENCE MIB Scalar Objects as defined in UTSI-VOIPRG-MIB.mib are listed below. Note: Please contact your UTStarcom, Inc Network Consultant or Sales representative for the UTSI-VOIPRG-MIB.mib file. MIB Scalar Objects Table 47 MIB Scalar Objects Table Node / OID Description Settings System Status The device status. It will be queried by SNMP platform. INTEGER 1.3.6.1.4.1.4684.1.1.0 ■ normal(1) read-only current ■ minor(2) ■ major(3) systemVersion 1.3.6.1.4.1.4684.1.2.
APPENDIX D: IAN-02EX SNMP MIB REFERENCE Table 47 MIB Scalar Objects Table Node / OID Description Settings rgCommonDeviceType Device type of device. DisplayString (0..255) 1.3.6.1.4.1.4684.5.4.1.6.0 read-only current rgCommonDeviceDescription 1.3.6.1.4.1.4684.5.4.1.7.0 read-only current rgCommonLastBuildDate A textual description of the system device. This value should DisplayString (0..
MIB Scalar Objects 131 Table 47 MIB Scalar Objects Table Node / OID Description Settings rgSysLedPower LED display status for power supply indicator. INTEGER 1.3.6.1.4.1.4684.5.4.2.9.0 ■ on(1) read-only current ■ off(2) ■ blink(3) rgSysLedLan LED display status for LAN linking indicator. INTEGER 1.3.6.1.4.1.4684.5.4.2.10.0 ■ on(1) read-only current ■ off(2) ■ blink(3) rgSysLedWan LED display status for WAN linking indicator. INTEGER 1.3.6.1.4.1.4684.5.4.2.11.
APPENDIX D: IAN-02EX SNMP MIB REFERENCE Table 47 MIB Scalar Objects Table Node / OID Description Settings rgVoipProtocol VoIP signaling protocol. INTEGER 1.3.6.1.4.1.4684.5.4.4.1.0 ■ mgcp(1) read-write current ■ sip(2) ■ h323(3) rgVoipMgcpLocalport The local listening port of MGCP stack. INTEGER (1..65535) The network IP address of the primary CallAgent. IpAddress The port number of the primary CallAgent. INTEGER (1..65536) The network IP address of the secondary CallAgent.
MIB Scalar Objects 133 Table 47 MIB Scalar Objects Table Node / OID Description Settings rgVoipSipProxyPort The port number of SIP proxy. INTEGER (1..65536) The network IP address of SIP registrar. IpAddress The port number of SIP registrar. INTEGER (1..65536) The period(in seconds) that the SIP registration will expire. Integer32 1.3.6.1.4.1.4684.5.4.4.3.3.0 read-write current rgVoipSipRegistrarAddress 1.3.6.1.4.1.4684.5.4.4.3.4.0 read-write current rgVoipSipRegistrarPort 1.3.6.1.4.1.4684.5.
APPENDIX D: IAN-02EX SNMP MIB REFERENCE Table 47 MIB Scalar Objects Table Node / OID Description Settings rgVoipCodecPrefer The preferred codec. (e.g., PCMU(G.711 u-law), PCMA(G.711 A-law), G.729A, G.723.1). INTEGER 1.3.6.1.4.1.4684.5.4.4.6.0 read-write current ■ pcmu(1) ■ pcma(2) ■ g729a(3) ■ g7231(4) default = pcmu rgVoipCodecVad Enable/Disable Voice Activity Detection(VAD). 1.3.6.1.4.1.4684.5.4.4.7.0 read-write current rgVoipFaxT38 Enable/Disable T.38 fax.
MIB Scalar Objects 135 Table 47 MIB Scalar Objects Table Node / OID Description Settings rgCallHistoryVoipOutCount The outgoing count of Call History entry. Counter32 The total number of successful placed outgoing call. Counter32 The total number of failed placed outgoing call. Counter32 The incoming count of Call History entry. Counter32 The outgoing count of Call History entry. Counter32 Select the tone type you want to config.
APPENDIX D: IAN-02EX SNMP MIB REFERENCE Table 47 MIB Scalar Objects Table Node / OID Description Settings mgToneOperation Enable/Disable tone modulation by tone type. INTEGER 1.3.6.1.4.1.4684.5.4.6.8.0 ■ on(1) read-write current ■ off(2) rgMgtDhcpServerIp The network IP address of the local DHCP server for LAN. IpAddress The network IP address of primary DNS server. IpAddress The network IP address of secondary DNS server. IpAddress The network IP address of PPPoE server.
MIB Scalar Objects 137 Table 47 MIB Scalar Objects Table Node / OID Description Settings rgMgtNtpExpires The period(in seconds) of retrieving time from NTP server. Integer32 Synchronize local time with ntp server. INTEGER 1.3.6.1.4.1.4684.5.4.7.17.0 read-write current rgMgtNtpSync 1.3.6.1.4.1.4684.5.4.7.18.0 ■ on(1) read-write current ■ off(2) default = off rgMgtSyslogServerAddress The network IP address of the syslog server. IpAddress The port number of the syslog server. INTEGER (1..
APPENDIX D: IAN-02EX SNMP MIB REFERENCE Table 47 MIB Scalar Objects Table Node / OID Description Settings rgEmsSnmpTrapCommunity The snmp trap community name of system. DisplayString (0..255) 1.3.6.1.4.1.4684.5.4.8.3.0 read-write current rgEmsSnmpTrapIP1 The network IP address of SNMP server for receiving traps. IpAddress 1.3.6.1.4.1.4684.5.4.8.4.0 read-write current rgEmsSnmpTrapIP2 The network IP address of SNMP server for receiving traps. IpAddress 1.3.6.1.4.1.4684.5.4.8.5.
systemInformationTable 139 Table 47 MIB Scalar Objects Table Node / OID Description Settings notificationSeq Notification sequence number Integer32 Notification class type INTEGER 1.3.6.1.4.1.4684.5.4.20.1.0 accessible-for-notify current notificationClass 1.3.6.1.4.1.4684.5.4.20.2.0 ■ fault(4) accessible-for-notify current ■ restore(5) ■ event(6) notificationPortIdx Notification port index number Integer32 Notification soft switch number Integer32 1.3.6.1.4.1.4684.5.4.20.3.
APPENDIX D: IAN-02EX SNMP MIB REFERENCE Table 48 System Information Table Node / OID Description Settings loginUserName password of supervisor DisplayString (0..40) password of supervisor DisplayString (0..40) 1.3.6.1.4.1.4684.5.1.1.1.1.1.1.1.48 read-write current loginPasswd 1.3.6.1.4.1.4684.5.1.1.1.1.1.1.1.
rgVoipSpeedDialTable 141 Indexed by: ■ rgPortIndex Table 50 rg Port Table Node / OID Description Settings rgPortIndex Index variable to access the RgPortEntry objects of the rgPortTable. INTEGER (1..256) The user name (or phone number) of the port. DisplayString (0..255) The user password of the port. DisplayString (0..255) The display name of the port. DisplayString (0..255) The RTP port number of the port to send/receive RTP packet. INTEGER (1..65536) LED displays status for the port.
APPENDIX D: IAN-02EX SNMP MIB REFERENCE Indexed by: ■ rgVoipSpeedDialIndex Table 51 rg Voip Speed Dial Table Node / OID Description Settings rgVoipSpeedDialIndex Index variable to access the RgVoipSpeedDialEntry objects of the rgVoipSpeedDialTable. INTEGER (1..300) Display digitmap string and length of the entry. DisplayString (0..255) 1.3.6.1.4.1.4684.5.4.4.15.2.1.1 not-accessible current rgVoipSpeedDialString 1.3.6.1.4.1.4684.5.4.4.15.2.1.
rgCallHistoryTable 143 Indexed by: ■ rgCallHistoryIndex Table 53 rg Call History Table Node / OID Description Settings rgCallHistoryIndex Index variable to access the RgCallHistoryEntry objects of the rgCallHistoryTable. INTEGER (1..500) The attributed port number of the Call History. INTEGER (1..65536) The direction of the call in the Call history. The (1)send indicates that this call is a outgoing call and the (2)recv indicates that this call is a incoming call. INTEGER 1.3.6.1.4.1.4684.5.4.
APPENDIX D: IAN-02EX SNMP MIB REFERENCE Table 53 rg Call History Table Node / OID Description rgCallHistoryTxOctets The total number of payload octets (not including header or Integer32 padding) transmitted in RTP data packets during a call in the Call History. 1.3.6.1.4.1.4684.5.4.5.1.1.13 Settings read-only current rgCallHistoryRxOctets The total number of payload octets (not including header or Integer32 padding) received in RTP data packets during a call in the Call History. 1.3.6.1.4.1.
Trap 145 Table 54 rg History AlarmTable Node / OID Description Settings rgHistoryAlarmSeverity alarm severity INTEGER 1.3.6.1.4.1.4684.5.4.10.3.1.5 ■ cleared(0) read-only current ■ major(1) ■ minor(2) ■ alert(3) Trap rgStart Table 55 rgStart Table Display rgStart Description RG start up (cold start) Probable cause none specified Severity none specified State none specified Trap Name rgStart ID notification OID 1.3.6.1.4.1.4684.5.4.21.
APPENDIX D: IAN-02EX SNMP MIB REFERENCE Table 58 Trap Variables VarBind Description Settings rgSysIpAddr The IP address of system. IpAddress 1.3.6.1.4.1.4684.5.4.2.4.0 rgPortFault Table 59 rgPortFault Table Display rgPortFault Description VoIP Port fault Probable cause none specified Severity none specified State none specified Trap Name rgPortFault ID notification OID 1.3.6.1.4.1.4684.5.4.21.
Trap 147 Table 62 Trap Variables VarBind Description Settings notificationSeq Notification sequence number Integer32 Notification class type INTEGER 1.3.6.1.4.1.4684.5.4.20.1.0 notificationClass 1.3.6.1.4.1.4684.5.4.20.2.0 notificationSoftSwitchIdx Notification soft switch number ■ fault(4) ■ restore(5) ■ event(6) Integer32 1.3.6.1.4.1.4684.5.4.20.4.
APPENDIX D: IAN-02EX SNMP MIB REFERENCE Table 65 rgLoadFail Table State none specified Trap Name rgLoadFail ID notification OID 1.3.6.1.4.1.4684.5.4.21.6 Table 66 Trap Variables VarBind Description Settings notificationSeq Notification sequence number Integer32 Notification class type INTEGER 1.3.6.1.4.1.4684.5.4.20.1.0 notificationClass 1.3.6.1.4.1.4684.5.4.20.2.
Syntax Types 149 Table 69 rgAlarmStatusChange Table Trap Name rgAlarmStatusChange ID notification OID 1.3.6.1.4.1.4684.5.4.21.8 Table 70 Trap Variables VarBind Description Settings notificationSeq Notification sequence number Integer32 1.3.6.1.4.1.4684.5.4.20.1.0 rgLedChange Table 71 rgLedChange Table Display rgLedChange Description LED status has changed Probable cause none specified Severity none specified State none specified Trap Name rgLedChange ID notification OID 1.3.6.1.4.
APPENDIX D: IAN-02EX SNMP MIB REFERENCE Table 73 Syntax Types Table iAN-02EX Administrator Manual Type Description Settings ProbableCause probable cause for current alarm INTEGER ■ proCau-wanLOL(1) ■ proCau-dhcp(2) ■ proCau-softSwitch(3) ■ proCau-acFail(4) ■ proCau-confExhaust(5) ■ proCau-portFail(6) ■ unknown(255) Part Number UTSI-NJTC-200323150117 June 2005
E Upgrade Procedure UPGRADE PROCEDURE Follow the procedures below to upgrade Generic units from V1.8.2.2a or interim Generic release to V1.8.2.19a. 1 Step1 ■ Connect PC to LAN side. ■ Connect ATA using ip-address 192.168.0.1 ■ Please verify using ipconfig command on the PC connected to the LAN side. ■ The ATA on the LAN side should get ip-address 192.268.0.2 ■ Login=supervisor password=utstar ■ System screen should be available on the PC connected to the LAN side. ■ Display should show V1.8.
APPENDIX E: UPGRADE PROCEDURE ■ Connect PC to LAN side ■ Please verify using ipconfig command on the PC connected to the LAN side ■ Connect ATA using ip-address 172.25.25.1 ■ ATA on the LAN side should get ip-address 172.25.25.2 ■ Login=supervisor password=utstar Upgrade Notes LAN side ip-address change WAN side Static ip-address configuration. The upgrade from V1.8.2.2a (Generic) units to V1.8.2.19a will change the default LAN side ip-address from 192.168.0.x to 172.25.25.1.
