Install Manual

200mW RP Installation RPC/RP Manual
WLL-200mW-RP-IN-1.0 25July2000
6
1 Equipment Description
This chapter describes all the components involved in the 200mW RP installation,
including the 200mW RP and the joint box.
1.1 200mW RP
This section represents the 200mW RP installation.
1.1.1 List of Component Parts
Items Quantity Model No. and DWG No. Company
1 200mWRP Main Unit 1 EA-7T56 PANASONIC
2 Screw for CS installation 1 XYN4•F18V PANASONIC
3 Mounting Plate 1 1B14449C PANASONIC
4 Screw for Mounting Plate 4 3Z10076A PANASONIC
5 Spring Washer 4 XWA6V PANASONIC
6 Plane Washer 4 XWG6V PANASONIC
7 Nut 4 XNG6AV PANASONIC
8 Spare Fuse 2 TSC3A PANASONIC
9 Spare Fuse 1 TSC6.3A PANASONIC
Table 1: Component Parts
! NOTE: No. 8 and No. 9 are spare fuses. The spare fuse must be inserted in the
right place.
