Installation Guide

6
REPLACING THE FUSE
WARNING
Disconnect the power before replacing the fuse. Remove plug from receptacle or other outlet device.
Do not unplug by pulling on power cord. Do not remove or replace plug. The plug on the rope light
contains a safety device (fuse access cover). Discard product if the plug is damaged.
1a. Open fuse cover on plug by sliding cover toward
blades. (It may be necessary to use a small flathead
screwdriver to open cover.)
1b. One spare fuse is located in the plug. Turn plug over to
remove spare fuse.
2. Remove old fuse carefully. Gently pry the metal end
nearest the blade with a very small flathead screwdriver
to loosen, then turn plug over to remove. Discard old
fuse.
2
1a
1b
Old Fuse
Plug
Spare
Fuse
Plug
Cover
