Installation Guide

ManualsBrandsUtilitech ManualsLighting & Fans8.35-in W White Ceiling Flush Mount

Table Of Contents

Utilitech is a registered trademark

Lowes.com

Serial Number

Purchase Date

ATTACH YOUR RECEIPT HERE

8.35 IN. FLUSHMOUNT

ITEM #0002462

MODEL #MXL-205

Contact the customer service department at

1-866-994-4148, 8 a.m. - 6 p. m., EST, Monday – Thursday, 8 a.m. - 5 p.m., EST,

Friday.

TROUBLESHOOTING

Minor problems often can be fixed without the help of an electrician. Before doing any work

on the fixture, shut off power supply at the circuit breaker panel to avoid electrical shock.

Problem

Fixture doesn't light.

Possible Cause

1.Power is off.

2.Bad wire connection.

3.Defective bulb (s).

4.Defective wall switch.

Circuit breaker trips

when light is turned on.

1.Crossed wires or power

wire is grounded out.

Corrective Action

1.Check circuit breaker or wall

switch.

2.Check wire splices.

3.Replace bulb (s).

4.Replace switch.

1.Check wiring connections.

WARRANTY

The manufacturer warrants this lighting fixture to be free from defects in materials and

workmanship for a period of three (3) years from the date of original purchase by the

consumer. We will repair or replace (at our option) the unit in the original color, and style if

available, or in a similar color and style if the original item has been discontinued, without

charge, exclusive of bulbs. Defective units must be properly packed and returned to the

manufacturer with a letter of explanation and your original purchase receipt showing date of

purchase. Call 1-866-994-4148 to obtain a Return Authorization number and an address

where to ship your defective product. Note: No C. O. D. shipments will be accepted. The

liability of the manufacturer is in any case limited to replacement of the defective light fixture

product. The manufacturer will not be liable for any other loss, damage, or injury which is

caused by the product. This limitation upon the liability of the manufacturer includes any

loss, damage, or injury which is (I) to person or property or otherwise; (II) incidental or

consequential in nature; (III) based upon theories of warranty , contract, negligence, strict

liability, tort, or otherwise; or (IV) directly or indirectly related to the sale, use, or repair of

the product. This warranty gives you specific rights, and you may also have other rights

which vary from state to state.

REPLACEMENT PARTS LIST

In the event that you are missing a part or have questions regarding installation, please call

the customer service department at 1-866-994-4148, 8 a.m. - 6 p. m.,

EST, Monday – Thursday, 8 a.m. - 5 p.m., EST, Friday.

Part Description Part#

C Diffuser D4313

AA Wire Nut HDW4313

BB 1-1/2in.Machine Screw HDW4313

CC Pull Chain Extension HDW4313

Lowes.com

PRINTED IN CHINA

CEILING FIXTURE
