Installation Guide

4
ASSEMBLY INSTRUCTIONS
1. Carefully remove all the parts from the

large, smooth workspace. Remove the packing
material and uncoil the rope light. Be careful not
to cut or nick the rope light (A).
1
A
PREPARATION
Before beginning assembly of product, make sure all parts are present. Compare parts with package
contents list and hardware contents list. If any part is missing or damaged, do not attempt to assem-
ble the product.
Estimated Assembly Time: 35 minutes
Tools Required for Assembly (not included): Phillips Screwdriver, safety glasses
Helpful Tools (not included): Ladder
2. Push the rope light (A) into power cord (B) by
aligning the cord adapters and screwing the
plastic ring from the rope light (A) onto thread of
the power cord (B). Be sure to screw the plastic
ring onto the power cord (B) until tight.
2
A
B
21
INSTRUCCIONES DE ENSAMBLAJE
5. Enchufe el cordón de luces en el tomacorriente
más cercano para encenderlo.
ADVERTENCIA: Si instala el cordón de luces
en exteriores deberá usar un tomacorriente con
interruptor de circuito de falla de puesta a tierra
(GFCI) para que su funcionamiento sea seguro.
5
Aditamentos utilizados
3. Fije los sujetadores de montaje (C) con los

madera. Los sujetadores de montaje (C) deben
estar separados de forma pareja a no más
de 0,91 m de distancia. Asegúrese de que la
distancia entre las dos líneas de los cordones
de luces sea de al menos 1,27 cm.
3
M3 x 16 mm
Tornillo de montaje
x 24
AA
AA
C
4. Encaje el cordón de luces (A) en los sujetadores
de montaje (C).
4
A
C
