Installation Guide

OPERATING INSTRUCTIONS

1. Test GFCI (Ground Fault Circuit Interrupter) plug BEFORE EACH USE.

Plug GFCI into power outlet. Press RESET button (b).

Indicator (a) should turn red.

CARE AND MAINTENANCE

TROUBLESHOOTING

The fan fails to

operate.

1. Fan may not be plugged in.

1. Make sure the fan is plugged in

and electrical outlet is working

properly.

2.There may some be obstructions

in the fan.

2. Check for any obstruction. If you find

an obstruction, turn the fan to “0”.

Unplug the fan and carefully remove

the obstruction. Plug the fan in and

turn it on again, referring to the

OPERATING INSTRUCTIONS.

PROBLEM

Press TEST button (c). Indicator (a) should turn off.

GFCI plug is tripped.

Press RESET button (b) again for use.

DO NOT USE FAN IF ABOVE TEST FAILS.

Call customer service for assistance.

2. ADJUSTING AIR SPEED

The fan has three speeds (LOW, MEDIUM and HIGH).

Pull the chain (e) of the unit to adjust air flow to desired speed.

3. USING THE OSCILLATING FEATURE

Pressing the oscillation knob (d) will allow the fan head to be

turned. Pulling up on the oscillation knob (d) w ill lock the fan head

at the desired position.

Oscillating feature

not working.

1. Oscillating feature is not turned on.

Make sure the oscillation knob is

pressed down.

Unplug the appliance before cleaning.Don’t use

any water for cleaning metal surfaces.

In order to remove the dust from the protective screen, use a vacuum cleaner or remove

the front protective screen by removing the securing screw on the ed

with a screwdriver. After cleaning, remount the safety screen. After doing this, fasten the

securing screw on the edge of the protective screen.
