Installation Guide

SAFETY INFORMATION
PREPARATION
Please read and understand this entire manual before attempting to assemble, operate or install
the product.
CAUTION
Before beginning assembly of product, make sure all parts are present. Compare parts with package
contents list and hardware contents list. If any part is missing or damaged, do not attempt to
assemble the product.
Estimated Assembly Time: 20 minutes
WARNING
READ AND SAVE THESE INSTRUCTIONS
1. Please unplug the fan from the socket and clean it with a soft cloth.
2. Do not submerge the fan in liquids.
3. Please submerge the fan in liquids.fit the guard onto fan before starting up the fan.
4. This fan is not intended for use by people (including children) with reduced physical, sensory
or mental capabilities or lack of experience an d knowledge unless they have been given
supervision or instruction concerning use of the fan by a person responsible for their safety.
Supervise children to ensure they do not play with the fan.
1
Unplug the fan before moving it or performing maintenance. Don’t touch the fan when your
hands are wet.
2. Those who are not qualified electricians should not disassemble, repair or rebuild the fan.
3. Unplug the fan when it is not in use.
4. Don’t unplug the fan by holding the cable cord. Unplug by holding the plug.
5. Don’t use the fan when there is damage to the cable cord or plug.
6. Don’t use the fan with an extension cord.
7. Don’t use the fan close to fires.
8. Don’t insert your hand or other objects into the guard or near movable parts.
9. To reduce the risk of fire or electric shock, do not use this fan with any solid-state speed
control device.
10. If the supply cord is damaged, it has to be replaced by the manufacturer, its service agent or
similarly qualified persons in order to avoid hazard.
Tools Required fo rAssembly (not included): Phillips Screwdriver, wrench
HARDWARE CONTENTS (shown actual size)
Screw
Qty.5
3
AA BB
Qty.3
Nut
CC
Bushing
DD EE
Qty.1
Qty.1
Qty.1
FF
GG HH
Nut
Qty.1 Qty.1
Qty.1
M6x12
M5x6
M6
M6x45
M8
M8x45
FF
φ12
φ15
II
JJ
KK
φ18
φ5
M5×3.5
LL
M6x16
Screw
Bolt
Bolt
Bowl
Washer
Qty.4
Nut
Qty.4
Qty.4
Screw
Qty.2
Spring
Washer
Bushing
