9. Troubleshooting
Detector does not power up properly or reports low battery
Be sure the battery is fully seated within the battery compartment and
the polarity is correct.
Check the battery voltage (3.0 VDC nominal).
Control Panel does not respond
Use a wireless RF Sniffer to confirm that the product is sending
messages for activation.
Be sure the detector is enrolled into the control panel properly.
Be sure you are using a compatible control panel.
Tamper condition does not restore
Be sure the product is installed properly onto the mounting plate and
the mounting plate has a magnet.
Be sure there are no trouble indications at the detector.
Be sure you are using a compatible control panel.
If a tamper notification occurs
Be sure you are using a compatible control panel.
Be sure the control panel is in sensor test mode during sensor testing.
Alarm condition does not restore
Be sure the heat has cleared at the product.
Be sure you are using a compatible control panel.
If unit continues to be non-operable then contact customer service for
further instructions.
10. Specifications
Compatible panels DLC-100
RF Wireless Frequency 915 MHz (NA)
RF Distance – LOS
See Section 6.
Power 3.0 VDC, Two lithium batteries
Battery type
Panasonic
®
CR123A
Duracell DL123A
Standby Current
35 µA (typically)
Battery life 5 years (typically)
Heat Detection - Fixed 135°F ± 5°F (57.2°C ± 2.8°C)
Heat Rate-of-Rise
15°F/min>85°F (8.3°C/min>
29.44°C)
Audible alarm 85 dBA @ 10’ (3M) temporal 3
Low Battery Beep 1 every 45 seconds.
Weight w/batteries 0.20 lbs. / 0.09 kg
Dimensions 5.6" x 2.4" (14.2cm x 6.1cm)
Storage temperature -4 to 140°F (-20 to 60°C)
Operating environment 32 to 100°F (0 to 38°C)
Relative Humidity 0 to 95% non-condensing
11. Regulatory Information – pending agency approvals.
Manufacturer: Edwards, A Division of Walter Kidde Portable Equipment,
Inc. (Edwards)
RoHS Directive
2011/65/EC RoHS Compliant. Hereby, Edwards declares that this
product does not contain lead, mercury, cadmium, hexavalent
chromium, polybrominated biphenyls (PBB) or polybrominated diphenyl
ethers (PBDE) in more than the percentage specified by EU directive
2011/65/EC, except exemptions stated in EU directive 2011/65/EC
annex.
Agency Rating
ANSI/UL521, UL539, CSFM
FCC Compliance
FCC ID: QPY-HD915FFH
IC: 8308B-HD915FFH
The device complies with part 15 of the FCC Rules as well as Industry
Canada Rules and Regulations license-exempt RSS standard(s).
Operation is subject to the following two conditions: (1) This device may
not cause harmful interference, and (2) this device must accept any
interference received, including interference that may cause undesired
operation.
Conformité Réglementaire
Ce dispositif est conforme à la réglementation de la IC et (Partie 15) de
la FCC. Son fonctionnement est soumis à deux conditions: (1) ce
dispositif ne doit pas causer d’interférences nuisibles, et (2) ce dispositif
doit accepter toute interférence reçue, y compris les interférences
pouvant entraîner des conditions de fonctionnement indésirables.
WARNING: Changes to Section 11 – Regulatory Information is
strictly prohibited. Any changes or modification made to the product
without the permission of the manufacturer could void the user’s
authority to use this product.
CAUTION (AS REQUIRED BY THE CALIFORNIA STATE FIRE MARSHAL)
“Early warning fire detection is best achieved by the installation of fire
detection equipment in all rooms and areas of the household as
follows. A smoke alarm installed in each separate sleeping (in the
vicinity of, but outside of the bedrooms), and heat or smoke alarms in
the living rooms, dining rooms, bedrooms, kitchens, hallways, attics,
furnace rooms, closets, utility and storage rooms, basements, and
attached garages.”
12. Product Information
Fire Prevention and Escape
The purpose of an early warning alarm is to detect the presence of fire
in its early stages and sound an alarm giving the occupant(s) time to
exit the premises safely.
Avoid Fire Hazards
No detection device can protect life in all situations. Therefore,
safeguards should be taken to avoid potentially dangerous situations
as follows:
o Do not smoke in bed.
o Do not leave children home alone.
o Never clean with flammable liquids such as gasoline.
o Properly store materials. Use general good housekeeping
techniques to keep your home neat and tidy. A cluttered
basement, attic, or other storage area is an open invitation to
fire.
o Use combustible materials and electrical appliances carefully
and only for their intended uses. Do not overload electrical
outlets
