A-11
Appendix
Supported Paper Sizes
Paper of the following sizes is supported by the machine.
Measurements in the table take into account a ±0.7 mm dimensional accuracy for length and width. Corner angles must be
90° ± 0.2°.
Smoothness
The paper surface should be smooth, but it must be uncoated. With paper that is too smooth and slippery, several sheets
may accidentally be supplied at once, causing jams.
Basis Weight
In countries that use the metric system, basis weight is the weight in grams of one sheet of paper one square meter in area.
In the United States, basis weight is the weight in pounds of one ream (500 sheets) of paper cut to the standard size (or
trade size) for a specific grade of paper. Paper that is too heavy or too light may be supplied incorrectly or cause paper jams,
which may cause excessive wear of the machine. Mixed paper weight (i.e., thickness) may cause several sheets to be
supplied at once accidentally and may also cause blurring or other printing problems if the toner fails to adhere correctly.
Multi Purpose Tray Cassette or Multi Purpose Tray
A6-R (105 × 148 mm) A3 (297 × 420 mm)
B6-R (128 × 182 mm) B4 (257 × 364 mm)
Hagaki (100×148mm) A4 (297 × 210 mm)
Oufuku hagaki (148 × 200 mm) A4-R (210 × 297 mm)
Executive (7 1/4 ×10 1/2") B5 (257 × 182 mm)
Envelope DL (110 × 220 mm) B5-R (182 × 257 mm)
Envelope C5 (162 × 229mm) A5-R (148 × 210 mm)
Envelope C4 (229 × 324mm) Folio (210 × 330 mm)
ISO B5 (176 × 250 mm) Ledger
Envelope #10 (Commercial #10) (4 1/8 × 9 1/2")
Legal
Envelope #9 (Commercial #9) (3 7/8 × 8 7/8")
Letter
Envelope #6 (Commercial #6 3/4) (3 5/8 × 6 1/2")
Letter-R
Envelope Monarch (3 7/8 ×7 1/2") Statement-R
Youkei 2 (114 × 162 mm) Oficio II
Youkei 4 (105 × 235 mm) 12 × 18"
Size Entry (98 × 148 to 297 × 1,220 mm)
8K (273 × 394 mm)
16K (273 × 197 mm)
16K-R (197 × 273 mm)
216 × 340 mm
