8-35
Troubleshooting
3 Open the conveyor guide (D6) and remove the jammed paper.
4 Close the conveyor guide (D6).
5 Open the conveyor guide (D4) and remove the jammed paper.
6 Close the conveyor guide (D4) and front cover 1.
Note If it is difficult to remove the jammed paper, turn feed
knob D3 until the jammed paper is in a location where it is
easy to remove.
