8-17
Troubleshooting
D Paper is jammed at the MP tray or
inside the printer.
page 8-25
E Paper is jammed in the right cover
section.
page 8-26
F Paper is jammed at the duplex
unit.
page 8-29
page 8-30
G Paper is jammed at the bridge unit. page 8-32
H Paper is jammed at the optional
document finisher.
page 8-32
page 8-34
page 8-39
Paper Jam Message
Paper jam
location
Description
Reference
Page
Paper jammed
at MP tray.
[ Help ]
Paper jammed
in right
cover #.
[ Help ]
Paper jammed
in the duplex
unit.
[ Help ]
Paper
jammed in the
bridge unit.
[ Help ]
Paper
jammed in the
finisher.
[ Help ]
Paper
jammed in the
finisher.
[ Help ]
