6-129
Operation Panel
Op Functions (Optional application settings)
You can use the optional applications installed on this machine.
Application
The applications listed below are installed on this machine.
You can use these applications for a limited period on a trial basis.
• DATA SECURITY (Data Security Kit(E))
• ID CARD (Card Authentication Kit(B))
• UG-33 (ThinPrint)
• UG-34 (Emulation)
The option available in Op Functions menu are as follows:
• Starting Application Use...6-129
• Checking Application Details...6-132
Starting Application Use
Use the procedure below to start using an application.
1 Press [Menu].
2 Press or to select Op Functions.
3 Press [OK]. The Login screen appears.
4 With the Login User Name entry field selected, press [OK]. The
Login User Name entry screen is displayed.
5 Enter the Login User Name using the numeric keys then press [OK].
The log in screen reappears.
Note Restrictions such as the number of times the application can be used during the trial period differ depending
on the application.
Note When user login administration is set:
• When logged in as an administrator, the log in screen is
not displayed and the Op Functions menu screen is
displayed.
• The setting is not possible when logged in as anyone other
than an administrator. Log in again as an administrator.
Note The initial setting for the administrator's Login User
Name is "Admin".
For details on entering characters, refer to Character Entry
Method on page A-6.
Login User Name:
O
b
/******************-
Login Password:
[ Login ]
Login User Name:
a
b
*
ABC
[ Text ]
