Operation Panel
6-90
HTTPS (SSL Server HTTPS setting)
HTTPS (HyperText Transfer Protocol Secure) is a protocol that adds SSL data encryption, message authentication and a
digital signature function to the HTTP protocol used for data transfer between WWW servers and clients.
S-HTTP is a similar protocol, but HTTPS differs in that it uses SSL. The default setting is On.
1 In the SSL Setting menu, press or to select HTTPS.
2 Press [OK]. The HTTPS screen appears.
3 Press or to select whether HTTPS is enabled.
4 Press [OK]. The HTTPS setting is set and the SSL Setting menu
reappears.
IPSec (IPSec setting)
IPSec (IP Security Protocol) is a security protocol adopted as the standard by the IETF for authentication and encryption in
the third network layer (IP layer).
It can be used with both IPv4 and IPv6.
The default setting is Off.
1 In the Network Security menu, press or to select IPSec.
2 Press [OK]. The IPSec screen appears.
3 Press or to select whether IPSec is enabled.
4 Press [OK]. The IPSec setting is set and the Network Security menu
reappears.
ThinPrint (ThinPrint setting)
Select whether or not to communicate using ThinPrint. SSL settings can also be selected. The default setting is On.
1 In the Network Security menu, press or to select ThinPrint.
2 Press [OK]. The ThinPrint menu screen appears.
HTTPS:
a
b
1
Off
********************-
2
*On
Note IPv4 uses 32-bit IP addresses and IPv6 uses 128-bit IP addresses.
IPSec:
a
b
********************-
2
On
1
*Off
Note Thin Print is only displayed when the optional UG-33 has been activated. Thin Print is only supported in
Europe.
ThinPrint:
a
b
********************-
2
ThinPrintOverSSL
[ Exit ]
1
Off/On
