6-85
Operation Panel
7 Press [OK]. The Login Password entry screen is displayed.
8 Enter the Login Password with the numeric keys then press [OK].
The login screen reappears.
9 Pressing [Login] ([Right Select]). If the entered Login User Name
and Login Password are correct, the Security menu screen appears.
Network Security (Network security setting)
Use this procedure to specify the security settings for each of the network protocols used.
The options available in Network Security are as follows:
• WSD-PRINT (WSD-PRINT setting)...6-86
• Enhanced WSD (Enhanced WSD setting)...6-86
• EnhancedWSD(SSL) (EnhancedWSD(SSL) setting)...6-86
• IPP (IPP setting)...6-87
• SSL Setting (SSL Server setting)...6-87
• IPSec (IPSec setting)...6-90
• ThinPrint (ThinPrint setting)...6-90
• LAN Interface (LAN Interface setting)...6-91
1 In the Security menu, press or to select Network Security.
2 Press [OK]. The Network Security menu screen appears.
Note The initial setting for the administrator's Login
Password is "Admin".
For details on entering characters, refer to Character Entry
Method on page A-6.
Login Password:
a
b
*
ABC
[ Text ]
Login User Name:
O
b
Admin
Login Password:
/******************-
[ Login ]
●●●●●●●●●●
Security:
a
b
********************-
2
I/F Block Set.
3
Security Level
[ Exit ]
1
Network Security
IMPORTANT Check with your network administrator when selecting network settings.
Network Security:
a
b
********************-
2
Enhanced WSD
3
EnhancedWSD(SSL)
[ Exit ]
1
WSD-PRINT
