Operation Panel
6-50
3 Press or . The NetwkName(SSID) is displayed.
If the entire name shown as the NetwkName(SSID) will not fit on one
line, pressing [Detail] ([Right Select]) changes to a 3-line name
display.
Quick Setup (Quick setup for the wireless LAN)
When connecting to an access point which supports the automatic wireless LAN setup, you can select the connection
settings using Quick Setup.
1 In the Wireless Network menu, press or to select Quick
Setup.
2 Press [OK]. The Quick Setup menu screen appears.
The following operations are possible:
• AvailableNetwork (Display the access points)
• Push Button (Connect using Push Button)
• PIN (Device) (Connect using a PIN code (for the Wireless Network
Interface Kit))
• PIN (Terminal) (Connect using a PIN code (for the access point)
AvailableNetwork (Display the access points)
Displays the access points which can be connected to.
1 In the Quick Setup menu, press or to AvailableNetwork.
2 Press [OK]. The AvailableNetwork screen appears.
3 Press or to select the access point to connect to.
4 Press [OK]. The connection with the access point is started.
When it is necessary to enter an encryption key, the WEP Key entry
screen or Preshared Key entry screen appears.
When a WEP Key must be entered:
Enter the WEP Key using the numeric keys and press [OK].
ConnectionStatus:
P
b
NetwkName(SSID): 2/2
AAAA
[ Detail ]
Note If some of the NetwkName(SSID) are not displayed, press
[Detail] ([Right Select]) and all the Names will be displayed.
Detail:
O
b
ABCDEFGHIJKLMNOPQRSTU
VWXYZabcdefghijklmnop
qrstuvwxyz1234567890
Quick Setup:
a
b
********************-
2
Push Button
3
PIN (Device)
[ Exit ]
1
AvailableNetwork
Note Press [Refresh] ([Left Select]) to update the
information.
Note Up to 26 characters can be entered. For details on
entering characters, refer to Character Entry Method on page
A-6.
AvailableNetwork:
a
b
AccessPoint_001
AccessPoint_002
AccessPoint_003
[ Refresh ]
WEP Key:
a
b
0000000
0
ABC
[ Text ]
