Operation Panel
6-40
Network (Network settings)
This printer supports TCP/IP and TCP/IP (IPv6) protocols.
IP is an abbreviation for Internet Protocol. This printer routinely uses the TCP/IP (IPv4) protocol, but provides a separate
setting for the next-generation IP, IPv6.
TCP/IP (IPv4) uses 32-bit IP addresses, but the rapid growth in the number of Internet users has resulted in a shortage of
IP addresses. IPv6 was developed to expand the range of available IP addresses by using 128-bit IP addresses.
The options available in the Network settings are as follows:
• TCP/IP (Enable/Disable TCP/IP)...6-40
• IPv4 Setting (TCP/IP IPv4 settings)...6-41
• IPv6 Setting (TCP/IP IPv6 settings)...6-44
• Protocol Detail (Detailed settings for the network protocol)...6-46
• Restart Network (Restarting the network card)...6-47
1 In the Print Settings menu, press or to select Network.
2 Press [OK]. The Network menu screen appears.
3 Select TCP/IP Settings and press [OK]. The TCP/IP Settings
menu screen appears.
TCP/IP (Enable/Disable TCP/IP)
Select whether or not to use TCP/IP. The default setting is On.
IMPORTANT
After changing the setting, restart the network, or turn the machine OFF and then ON. For detailed
information on restarting the network, refer to Restart Network (Restarting the network card) on page 6-47.
1 In the TCP/IP Settings menu, press or to select TCP/IP.
2 Press [OK]. The TCP/IP screen appears.
3 Press or to select whether TCP/IP is enabled.
4 Press [OK]. The TCP/IP setting is set and the TCP/IP Set. menu
reappears.
Note Check with your network administrator when selecting the network setting. After all network related settings
have been done, restart the network. Refer to Restart Network (Restarting the network card) on page 6-47. This is
mandatory to make the settings effective!
When Embedded Web Server RX is used, network parameters and security settings can be conveniently changed
and checked from your PC. For more information, refer to the Embedded Web Server RX User Guide.
Network:
a
b
********************-
2
Restart Network
[ Exit ]
1
TCP/IP Settings
TCP/IP Settings:
a
b
********************-
2
IPv4 Setting
3
IPv6 Setting
[ Exit ]
1
TCP/IP
TCP/IP:
a
b
1
Off
********************-
2
*On
