Operation Panel
6-2
Report Print
Prints a report. The options available in the Report Print menu are as follows:
• Menu Map (Printing a menu map)...6-2
• Status Page (Printing a printer's status page)...6-4
• Font List (Printing a list of the printer's fonts)...6-6
• HDD File List (Printing a list of the files on the hard disk)...6-6
1 Press [MENU].
2 Press or to select Report Print.
3 Press [OK]. The Report Print menu appears showing a list of the
types of report that can be printed. Note that report types shown may
vary depending on which optional units are installed in the printer.
Menu Map (Printing a menu map)
The printer prints a full list of the menu selection system menu map.
1 In the Report Print menu, press or to select Menu Map.
2 Press [OK]. A confirmation message is displayed.
3 Press [Yes] ([Left Select]). The message Accepted. appears and
the printer prints the menu map.
Pressing [No] ([Right Select]) returns you to the Report Print menu
without printing the menu map.
Report Print:
a
b
********************-
2
Status Page
3
Font List
[ Exit ]
1
Menu Map
Note When Job Accounting is set but user login is not set,
the screen for entering Job Accounting information is
displayed. Enter the Account ID and press [OK].
Note The Menu numbers are printed on the Menu Map
outputted. It is possible to use the numeric keys to enter the
Menu number and display the settings required.
Example: Displaying the Menu Map printing menu
1 Press [Menu].
2 Press [1] on the Numeric Keys. The Report Print
menu appears.
3 Press [1] on the Numeric Keys. A confirmation message
is displayed.
Print.
Are you sure?
z
Menu Map
[ Yes ] [ No ]
