2-4
2AV/X
2-4-6
Timing chart No. 6 Continuous copying of an A3/11" × 17" original onto two sheets of A5R/5
1
/2" × 8
1
/2" copy paper from the lower drawer, magnification ratio 50%, ejection to the job separator
Start key
SM
DM
DDM
*1
RCL
PFCL-L
*1
MC REM
CL
RSW
ESW
JBESW
*2
TC REM
DB REM
CN28-1,3,4,6
CN12-16
CN8-18
CN4-10
CN8-3
CN4-3
CN12-2
CN3-7
CN12-6
CN16-7
CN4-5
CN4-4
1078 P
340 P
10524 P
185 ms
100 ms
6667 ms
500 ms
100 ms
270 ms
418 ms
418 ms
300 ms
270 ms
300 ms
474 ms
474 ms
1840 ms
30 s
1316 ms
9106 P
Fwd. rotation
Rev. rotation
*1: Optional for 15 cpm copier/standard for 20 cpm copier.
*2: Optional for both 15 cpm and 20 cpm copiers.
