Maintenance
Description
item No.
2AV/X
1-4-86
1-4
U244 Checking the DF switches
Description
Displays the status of the switches in the optional DF.
Purpose
To check if switches in the optional DF operate correctly.
Method
1. Press the start key.
2. Manually turn on and off each switch to check the status. When the on-status of a switch is detected, the
original size indicator or other LED corresponding to the operated switch on the operation panel lights.
LED Switch
A3/11" × 17" Original set switch (PI5)
A4R/8
1
/
2
" × 14" Original size width switch B (PI4)
A4/8
1
/
2
" × 11" Original size width switch C (PI3)
B4/LED below 8
1
/
2
" × 11" Original size width switch D (PI2)
B5R/5
1
/
2
" × 8
1
/
2
" Original size width switch E (PI1)
B5/11" × 8
1
/
2
" DF timing switch (DFTSW)
Folio/11" × 15" Original size length switch (OSLSW)
Maintenance indicator DF safety switch 2 (DFSSW2)
Memory overflow indicator DF safety switch 1 (DFSSW1)
Completion
Press the stop/clear key. The indication for selecting a maintenance item No. appears.
U250 Setting the maintenance cycle
Description
Displays and changes the maintenance cycle.
Purpose
To check and change the maintenance cycle.
Method
Press the start key. The current setting is displayed as follows:
Maintenance cycle (number of copies) = setting × 1000
Setting
1. Change the setting using the zoom +/– keys.
Description Setting range Initial setting Change in value per step
Maintenance cycle 0 to 600 100 1000 (copies)
For example, when set to 120, the maintenance cycle is set to 120000.
2. Press the start key. The value is set, and the indication for selecting a maintenance item No. appears.
Completion
To exit this maintenance item without changing the current setting, press the stop/clear key. The indication for
selecting a maintenance item No. appears.
