2AV/X
1-4-75
1-4
Maintenance
Description
item No.
U099
(cont.)
Method to set or check the original size detection threshold
1. Place an original on the contact glass and turn the original detection switch on. The original size detection
starts and detection data is displayed.
2. Change the detection item by lighting a copy exposure indicator using the copy exposure adjustment keys.
Copy exposure
Description Data range Remarks
Initial
indicator setting
Exp. 1 Scanner data threshold 0 to 255 Adjustable 170
Exp. 2 Time between original detection switch turning 0 to 100 ms Adjustable 50
on and reading-in of scanner data
Exp. 3 Detected original width 0 to 350 mm ———
Exp. 4 Original size detected by scanner data and 0 to 63* ———
original size sensor detection data
* See Paper size in U073 for the paper size for each setting.
3. To change the original size detection threshold, light exp. 1 or 2 and change the setting using the zoom +/–
keys.
4. Press the start key. The value is set.
5. Press the stop/clear key. The selected item appears.
Completion
Press the stop/clear key while a selection item is displayed. The indication for selecting a maintenance item No.
appears.
