Wireless Neighborhood - 74
Neighbors Access points that are neighbours of one or more of the clustered APs are
listed in the left column by SSID (Network Name).
An access point which is detected as a neighbour of a cluster member can also
be a cluster member itself. Neighbours who are also cluster members are
always shown at the top of the list with a heavy bar above the name and
include a location indicator.
The coloured bars to the right of each AP in the Neighbors list shows the signal
strength for each of the neighbour APs as detected by the cluster member
whose IP address is shown at the top of the column:
• Dark Blue Bar - A dark blue bar and a high signal strength number (for
example 50) indicates good signal strength from the neighbour as seen by
the AP whose IP address is shown at the top of the column.
• Lighter Blue Bar - A lighter blue bar and a lower signal strength number (for
example 20 or lower) indicates medium or weak signal strength from the
neighbour as seen by the AP whose IP address is shown at the top of the
column.
• White Bar - A white bar and the number 0 indicates that a neighbouring AP
that was detected by one of the cluster members cannot be detected by the
AP whose IP address is shown at the top of the column.
• Light Gray Bar - A light gray bar and no signal strength number indicates a
neighbour that is detected by other cluster members but not by the AP
whose IP address is shown at the top of the column.
• Dark Gray Bar - A dark gray bar and no signal strength number indicates
this is the AP whose IP address is shown at the top of the column.
Field Description
This access point is a cluster member and can be seen by the AP
whose IP address is 192.168.1.5 at a signal strength of 64...
... but it cannot be seen by the access
point whose address is 192.168.1.4.
