Technical data

Professional Access Point
Administrator Guide
Class Structure, Commands, and Examples - 250
dhcp-client DHCP client settings
dot11 IEEE 802.11
host Internet host settings
interface Network interface
ip-route IP route entry
log Log settings
mac-acl MAC address access list item
ntp Network Time Protocol client
portal Guest captive portal
radio Radio
radius-user RADIUS user
ssh SSH access to the command line interface
system System settings
telnet Telnet access to the command line interface
tx-queue Transmission queue parameters
wme-queue Transmission queue parameters for stations
• Example 5: Type "set mac" TAB, and the command will complete with the only matching option:
USR5453-AP# set mac-acl
• Example 6: Type "set cluster" TAB TAB, and the two matching options are displayed:
USR5453-AP# set cluster
cluster Clustering-based configuration settings
cluster-member Member of a cluster of like-configured access points
• Example 7: Type "add" TAB TAB (including a space after add) to get a list of all field options for the add
command.
USR5453-AP# add
basic-rate Basic rate of the radio
bridge-port Bridge ports of bridge interfaces
bss Basic Service Set of the radio
interface Network interface
mac-acl MAC address access list item
radius-user RADIUS user
supported-rate Supported rate of the radio
• Example 8: Type "remove" TAB TAB (including a space after remove) to get a list of all field options for
the remove command
USR5453-AP# remove
basic-rate Basic rate of the radio
bridge-port Bridge ports of bridge interfaces
bss Basic Service Set of the radio
interface Network interface
ip-route IP route entry
mac-acl MAC address access list item
radius-user RADIUS user
supported-rate Supported rates of the radio
CLI Class and Field Overview
The following is an introduction to the CLI classes and fields. For a complete reference guide, see “Class
