Instruction Sheet

Model SS-770-LR Giftbox
Model SS-770-LRC Clamshell
Smoke & Fire Alarm, Battery Operated
Standard Series
· Compact Size (4
1
/4” x 4
1
/4” x 1
3
/8”)
· Includes 9V Battery
· Audible Low Battery Indicator
· Ideal for Replacement of Most Existing Smoke
Alarms
· Separate Large Size 5
5
/8” (143mm) Mounting
Plate Attaches to any Standard Rectangular or
Octagon Junction Box and Covers Drywall Cutout
- for easy installation and coverage of drywall
cutouts.
· Fast and Easy Installation
· Alarm and Power Test Button
· Dual Chamber Ionization Sensor
· Mounting Hardware Included
· Chamber and cover designs protect alarm
from insects and contaminants.
· Loud 85 Decibel Horn
· Three Year Limited Warranty
All UNIVERSAL Smoke & Fire Alarms comply with the following authorities:
Underwriters Laboratories (UL), Federal Housing Authority (FHA), Housing and
Urban Development (HUD), National Fire Protection Association (NFPA), California
State Fire Marshal (CSFM)
ADDITIONAL OTHER VOLTAGES & FREQUENCIES AVAILABLE
OTHER COUNTRY REGULATORY APPROVALS AVAILABLE - OEM PROJECTS
UNIVERSAL SECURITY INSTRUMENTS, INC.
11407 CRONHILL DRIVE, SUITE A
OWINGS MILLS, MARYLAND 21117 USA
TELEPHONE: [phone] · FAX: [phone] · E-MAIL: [e-mail]
Visit Us on the Web! www.SmokeAlarms.com
UNIVERSAL brings over four decades of
manufacturing expertise to a full line of safety products.
SS-770-LRC
Size
Weight
UPC #
Cube
English (inches) metric (mm)
Giftbox
lbs. kg.
Master Carton (24 pcs)
0-42741-02770-0
1-00-42741-02770-7
SS-770-LR
Size
Weight
UPC #
Cube
English (inches) metric (mm)
Giftbox
lbs. kg.
Master Carton (24 pcs)
0-42741-00770-2
1-00-42741-77024-5
------
5.5 x 1.75 x 5.5 140 x 44 x 140
.41
0.19
11.5 1.00 Ft.
3
12 x 12 x 12 305 x 305 x 305
5.22
6.75 x 2.5 x 10.375 171 x 64 x 264
3.5
.50 ------
12 x 6.875 x 7.5
0.23
.36 Ft.
3
305 x 175 x 191 1.6
©
1996 UNIVERSAL SECURITY INSTRUMENTS, INC., Rev. 06/2013
