Instruction Sheet

NEVER use an open flame of any kind to test this smoke alarm. You might accidentally damage
or set fire to the smoke alarm or to your home. The built-in test switch accurately tests the
smoke alarm's operation as required by Underwriters Laboratories Inc. (UL).
(UTHA) Sensitivity Indicating Means
The sensitivity indicating means for this Smoke and Fire Alarm is the use of the analyzer for Smoke
Detectors Model 501-A or 501-A/Bat Aerosol Generator Manufactured by Gemini Scientific Corp.,
1122-B Aster Ave., Sunnyvale, CA 94086.
The
Equivalent UL 268 Light obscuration %/Ft as measured by this instrument must be within the
obscuration listed on the back of this alarm.
(UTHA) Go/No-Go Field Test
The Go/No-Go test for this smoke and fire alarm is to use one of the following UL listed can-type aerosol
smoke alarm testers. The instructions for use are printed on the canister. Home Safeguard, Model 25S.
If you choose to use an aerosol smoke product to test the smoke alarm, be certain to use
one that has been Listed to Underwriters Laboratories, Inc. Safety Standards and use it
only as directed. Use of non-UL Listed products or improper use of UL Listed products
may affect the smoke alarm's sensitivity.
(UTHA) MAINTENANCE:
The alarm is virtually maintenance free. However, under dusty conditions, a vacuum hose may
be used to clear the sensing chamber of dust.
Clean the alarm at least once a month to remove dust, dirt, insects or debris. Always turn off power
to alarm before cleaning. Using a soft brush or wand attachment to a vacuum cleaner, vacuum all sides
and cover of the alarm. Be sure all the vents are free of debris.
If the alarm is false alarming and cannot be restored to normal operation, the alarm should be replaced.
WEEKLY TESTING
This alarm is designed to act as a monitor, not for use as a short-term testing device, to
perform a quick check for the presence of CO or gas. WARNING: Natural gas (methane) is
highly explosive. An attempt to test the unit by exposing it to natural gas outside of a
controlled labatory environment can produce an explosion and death. NEVER use a gas
range or an open flame of any kind to test this alarm. You might accidentally damage or
set fire to the alarm or to your home. NEVER use vehicle exhaust to test the alarm! Exhaust
may cause permanent damage and voids your warranty. The built-in test switch accurately
tests the alarm operation as required by ANSI/UL2034 Standard for Safety. If, at any time,
you test the alarm and it does not perform as described, replace it immediately.
It is important to test this alarm every week to make sure it is working properly.
USING THE TEST FEATURE:
Press and release the TEST button on the alarm cover.
During testing, you will hear: 3 beeps (red LED on), 2 second pause, 3 beeps (red LED on), 6
second pause, 4 beeps (red LED on), 5 second pause, 1 beep (blue LED on).
If the alarm does not sound properly:
1. Make sure the AC power is applied and the battery is fresh and installed correctly.
2. Test the alarm again.
REGULAR MAINTENANCE
CLEANING YOUR ALARM:
Page 12
DO NOT use spray cleaning chemicals or insect sprays directly on or near the alarm. DO NOT
paint over the alarm. Doing so may permanently damage the alarm.
The outside can be wiped with a damp cloth. Do not use any household cleaning agents, ammonia-
based cleaners, paints, varnishes, compressed gas dusters or any other chemical on or near your
alarm. AFTER CLEANING, REINSTALL YOUR ALARM. TEST YOUR ALARM BY USING THE
TEST BUTTON.
