Comfort Panels
212 Operating Instructions, 03/2012, A5E03404994-02
Safety
HMI devices
Object Specification
KP400 Comfort
KTP400 Comfort
KP700 Comfort to
KP1200 Comfort
TP700 Comfort to
TP1200 Comfort
KP1500 Comfort,
TP1500 Comfort to
TP2200 Comfort
Number of user groups 50
Number of users 50
User view
Number of authorizations/
user permissions
32
Infotexts
HMI devices
Object Specification
KP400 Comfort
KTP400 Comfort
KP700 Comfort to
KP1200 Comfort
TP700 Comfort to
TP1200 Comfort
KP1500 Comfort,
TP1500 Comfort to
TP2200 Comfort
Length (no. of characters) 320 (depending on font)
For alarms Yes
For screens Yes
Infotexts
For screen objects (e.g. I/O
field, switch, button, invisible
button)
Yes
Additional functions
HMI devices
Object Specification
KP400 Comfort
KTP400 Comfort
KP700 Comfort to
KP1200 Comfort
TP700 Comfort to
TP1200 Comfort
KP1500 Comfort,
TP1500 Comfort to
TP2200 Comfort
Screen settings Touch screen calibration
1
Brightness setting
Yes
Yes
Language change Number of languages per
project
32
User-specific extension of
the functionality
Yes VBScript
Number of scripts 100 200
Graphic objects Vector and pixel graphics Yes
Trends Number 50 300 400
Task planner Number of tasks 10 48
Text objects Number 2500 40000
PROFIBUS DP direct keys Yes Direct keys
PROFINET IO direct keys Yes
1
For HMI devices with touch screen only
