Technical Support
Comfort Panels
210 Operating Instructions, 03/2012, A5E03404994-02
Tags, values and lists
HMI devices
Object Specification
KP400 Comfort
KTP400 Comfort
KP700 Comfort to
KP1200 Comfort
TP700 Comfort to
TP1200 Comfort
KP1500 Comfort,
TP1500 Comfort to
TP2200 Comfort
Tags Number 1024 2048 4096
Limit value monitoring Input/output Yes
Linear scaling Input/output Yes
Text lists Number 300 500
1
Graphics lists Number 100 500
1
1
The maximum total of text and graphics lists is 500.
Screens
HMI devices
Object Specification
KP400 Comfort
KTP400 Comfort
KP700 Comfort to
KP1200 Comfort
TP700 Comfort to
TP1200 Comfort
KP1500 Comfort,
TP1500 Comfort to
TP2200 Comfort
Number 500 750
Objects per screen 50 400 600
Tags per screen 50 400 600
Complex objects per screen
(for example, bars)
5 20 40
Screens
Template Yes
Recipes
HMI devices
Object Specification
KP400 Comfort
KTP400 Comfort
KP700 Comfort to
KP1200 Comfort
TP700 Comfort to
TP1200 Comfort
KP1500 Comfort,
TP1500 Comfort to
TP2200 Comfort
Number 100 300 500
Data records per recipe 200 500 1000
Entries per data record 200 1000 2000
Recipe memory 32 KB 256 KB 4 MB
Recipes
Storage location
1
Memory card (MMC/SD)
USB storage medium
Network drive
1
The number of recipe data records may be restricted by the capacity of the storage medium.
