Comfort Panels
Operating Instructions, 03/2012, A5E03404994-02
169
Technical specifications
8
8.1 Certificates and approvals
Approvals
CAUTION
The following overview shows possible approvals.
The HMI device itself is certified as shown on the rear panel labels.
CE approval
The HMI device meets the general and safety-related requirements of the EMC Directive
(2004/108/EC "Electromagnetic Compatibility") and conforms to the harmonized European
standards (EN) for programmable logic controllers published in the official gazettes of the
European Union:
● 94/9/EU "Devices and protection systems for use as prescribed in potentially explosive
areas" (Guidelines for Explosion Protection)
● EC Declaration of Conformity
The EC Declarations of Conformity are available to the relevant authorities at the following
address:
Siemens Aktiengesellschaft
Industry Sector
I IA AS FA WF AMB
PO Box 1963
D-92209 Amberg, Germany
