• Additional MLX-2 devices are assigned different RF ID numbers as they
are added.
• If necessary, double click a device to open the “Device Settings” window
and change the RF ID, as shown in the following figure.
“MLX-2 Device Settings” Window
• The ID code specified in the SIMPL Windows program must match the
RF-ID of each unit.
Programming Manager
Programming Manager is the view where programmers "program" a Crestron control
system by assigning signals to symbols. The symbol can be viewed by double
clicking on the icon or dragging it into Detail View. A description for each signal in
the symbol is described in the SIMPL Windows help file (F1).
Programming with VisionTools Pro-e
The MLX-2 LCD screens should be created in VisionTools Pro-e to allow selection
of functions, and control of system devices. Note that the MLX-2 design permits the
57 buttons to be programmed individually per project or for each page in a project.
The result is almost limitless functionality, with real time feedback of commands.
Example Program
An example program for the MLX-2 is available from the Crestron website
(http://www.crestron.com/exampleprograms).
