User's Manual

Crestron MLX-2 infiNET EX
™
LCD Handheld Remote
“PROGRAM DEVICE” Screen
PAGE 1/1
PROGRAM DEVICE
BASIC SETUP
VIEW TSID
SET RFID
RF CHANNEL
ACQUIRE
Setup Mode
In Setup Mode, use the keys on either side of the function name displayed on the
PROGRAM DEVICE screen to select that function.
The following paragraphs describe each of the setup options in the order listed in the
menus.
NOTE: Before beginning Setup Mode procedures, verify that the CEN-RFGW-EX
gateway is connected to the infiNET-EX network, and that the network is
operational.
To begin Setup Mode, press one of the keys on either side of the ACQUIRE option.
The screen displays navigation instructions that apply throughout the setup process.
Basic Navigation Screen
ACQUIRE Function
This function permits you to add the MLX-2 to your infiNET-EX network. From the
basic navigation screen, shown to the left, press h to enter the acquire function, and
press h again to start the process to add the MLX-2 to the network.
 If the MLX-2 is added to the network, the screen displays a “Success!”
message. Press h to continue. The display returns to the PROGRAM
DEVICE screen.
 If the acquire process is not successful, the screen displays the following
message for approximately five seconds:
“The node addition failed. Try again or reference the manual for more
assistance. Press h to continue.”
 If you press h in time, the display returns to the PROGRAM DEVICE
screen. Otherwise, the display returns to the startup screen.
“BASIC SETUP” Screen
BASIC SETUP
PAGE 1/1
VERSION INFO
CONTRAST
DISPLAY T/O
LIGHT T/O
BASIC SETUP Functions
From the PROGRAM DEVICE screen, select BASIC SETUP. The BASIC SETUP
screen, shown to the left, allows you to select and review the version information of
the software and firmware programs currently loaded on the MLX-2 remote, and to
review/adjust the contrast, display timeout, and backlight timeout settings.
PAGE 1/1
Use < / > to
navigate. At any
time, press and
hold HOME to
exit. Press >
to continue.
The process to
add this node
to your network
may take up to
90 seconds.
Press > to
Continue.
PAGE 1/1
Please wait for
the add process
to complete.
ADD ACTIVE
PAGE 1/1
PAGE 1/1
Success!
You have added
this remote as
a new node to
Your RF network.
Press > to
continue
Operations & Installation Guide – DOC. 6739 infiNET EX
™
LCD Handheld Remote: MLX-2 • 7
