UAD System Manual - 20 - Chapter 2: UAD Installation
Installed
Locations
The UAD Meter & Control Panel application and UAD documentation is cop-
ied to these locations on the hard drive during installation:
Windows • C:\Program Files\Universal Audio\Powered Plug-Ins
You can access these files from the Windows Start Menu at:
• Start>All Programs>UAD Powered Plug-Ins
The VST plug-in files are installed to the location specified during installation.
Mac • Startup Disk/Applications/Powered Plug-Ins Tools
The plug-in files are installed to the standardized OS X locations:
• VST: Startup Disk/Library/Audio/Plug-Ins/VST/Powered Plug-Ins
• Audio Units: Startup Disk/Library/Audio/Plug-Ins/Components
• RTAS: Startup Disk/Library/Application Support/Digidesign/Plug-Ins
UAD Hardware Installation
Note: The UAD software should be installed before installing the UAD DSP
device(s). See the previous section for software installation instructions.
UAD-2
SOLO/Laptop
UAD-2 SOLO/Laptop is a UAD product designed for use with the Express-
Card expansion slot typically found on notebook computers. It has its own set
of hardware connection and operation instructions. Refer to Chapter 10,
“UAD-2 SOLO/Laptop” for complete details.
UAD-2 Satellite The UAD-2 Satellite is a UAD product that is designed for use with the Firewire
port. This product has its own set of hardware connection and operation in-
structions. Refer to Chapter 11, “UAD-2 Satellite” for complete details.
About PCI and
PCI Express
PCI and PCI-X should not be confused with PCI Express (also known as PCIe).
PCIe is not compatible with PCI or PCI-X because PCIe uses a completely dif-
ferent connector (see Figure 1 on page 21).
UAD-2 SOLO, DUO, and QUAD cards are all PCIe cards. They will ONLY
work in PCI Express (PCIe) slots. Be careful to only install the UAD-2 card into
a PCIe slot.
