UAD Powered Plug-Ins Manual - 327 - Chapter 37: Nigel
Note: For the following descriptions of the Cabinet models and other refer-
ences that you may find throughout this manual, please be aware that Celes-
tion, Greenback, Oxford Blue, Marshall, Fender, Line 6, Pod, SansAmp,
Shure, ADA, Utah and any other manufacturer, model name, description,
and designations are all trademarks of their respective owners, which are in
no way associated or affiliated with Universal Audio. These trademarks and
names are used solely for the purpose of describing certain timbres produced
using Universal Audio’s exclusive modeling technology.
Cabinet
Abbreviations
Cabinet Type List
Table 20. Cabinet Abbreviation Descriptions
ABBREVIATION DESCRIPTION
1-12, 2-12, 4-12 One, two, or four twelve-inch speaker(s)
1-10, 2-10, 4-10 One, two, or four ten-inch speaker(s)
OB Open Back cabinet
SC Sealed Cabinet (closed back cabinet)
On Axis Mic close and perpendicular (at 90 degrees), off-center
Off Axis Mic close and angled, off-center
Edge Mic close and angled at edge of speaker
Far Mic approximately 2 feet from speaker
1-12 OB 90-watt Celestion (early 1990’s)
2-12 OB Left speaker: Oxford Blue, Right: Utah (both 60-watt, early 1960’s)
2-12 SC 90-watt Celestions (early 1990’s)
4-12 SC 25-watt Celestion Greenbacks (circa 1967)
British Emulation of Marshall effects box cabinet
NoCA FXB Emulation of ADA effects box cabinet
LA FXB Emulation of Line 6 Pod effects box cabinet
NY FXB Emulation of SansAmp effects box cabinet
Table 21. List of Cabinet Types
1-12 OB Off Axis 4-12 SC Edge
2-12 OB Off Axis 2-12 SC Far
1-12 OB On Axis 4-12 SC Far
2-12 OB On Axis 4-12 British
1-12 OB Edge 1-10 NoCA FXB
2-12 OB Edge 2-10 NoCA FXB
1-12 OB Far 4-10 NoCA FXB
2-12 OB Far 1-12 LA FXB
2-12 SC Off Axis 2-12 LA FXB
4-12 SC Off Axis 4-10 LA FXB
2-12 SC On Axis 1-12 NY FXB
4-12 SC On Axis
