6. Connect the gate reset loop leads to terminals 15 and 16 inside the gate.
Refer to the following table when wiring the Wash Select II unit to the barrier gate.
Wash Select II Phoenix
Connector Pin
Gate Terminal
J18, pin 1 50
J18, pin 2 1
J19, pin 1 42
J19, Pin 2 52
N/A 4822
The following diagram illustrates the proper wiring at the gate:
Figure 24. Gate Wiring
