WASH SELECT II
Document Number: WS21001 6
Document Title: Wash Select II POS Installation Manual
 Installation & Operation Manuals
 Keys & Lock core set
 (4) Bolts to secure top assembly to optional base
 (4) Washers to be used on bolts for optional base
1.3.3 Wash Select II – Option Packages
The following items should be added to the standard installation checklist, if that specific
option was purchased with it.
WASH SELECT II – CREDIT OPTION
 Extra Roll of Thermal Printer Paper
 IPTran credit modem
WASH SELECT II - SPEECH OPTION
 Microphone (for message recording)
WASH SELECT II PROXIMITY SWITCH OPTION
 Infrared Relay Block (installed on Wash Select II power supply cover)
WASH SELECT II – OPTIONAL BASE
 Base
 (4) Concrete Anchor Bolts
 (4) Washers
 (4) Nuts
WASH SELECT II – WASHPAY INTEGRATION
 CAT5E Ethernet Cable
 Expansion board
