Assembly Instructions

Page 5 OF 7
Step 3
Step 4
Adjust the Pre-installed Levelers on the bottom of Upper Leg Frame(B) and Lower Leg
Frame(C) until the Table is level with the ground.
3.1) Attach Upper Leg Frame(B)and Lower Leg Frame(C)to the bottom of Table
Top(A)using Bolt(①),Spring Washer(③),Washer(④) with Allen Key(⑤) as shown
above.
Do not fully tighten the Bolts.
3.2) Attach Upper Leg Frame(B)and Lower Leg Frame(C)to the bottom of Table
Top(A)using Bolt(①),Spring Washer(③),Washer(④) with Allen Key(⑤)as shown
above.
Tighten all Bolts fully in a sequential manner.
