XDECT R035 Bluetooth® For more exciting new products please visit our website: Australia: www.uniden.com.au New Zealand: www.uniden.co.
XDECT R035BT Series Owner’s Manual What's in the box? XDECT R035BT base with answering system and cordless handset You will also find: Battery cover Rechargeable battery (BT-694s) Telephone cord XDECT R003BT accessory handset and charger (with stand) Battery cover Rechargeable battery pack (BT-694s) If you purchased model number: XDECT R035BT XDECT R035BT+1 XDECT R035BT+2 XDECT R035BT+3 XDECT R035BT+4 XDECT R035BT+5 AC adapter (AAD-041S(M)) You should have: None 1 of each 2 of each 3 of each 4 of each
What’s in the manual? Getting Started............................. 1 Installing Your Phone................... 1 Setting Up the MobileLink Bluetooth™ Connection............ 2 Installing the Repeater/Charger(s) (if included).................................. 5 Using the Repeater...................... 6 Understanding Your Phone........... 9 Using the Menus........................ 14 Using Your Phone....................... 17 Learning the Basics.................... 17 Using Caller ID and Redial Lists..
CAUTION! Risk of explosion if battery is replaced by an incorrect type! Dispose of used batteries according to the instructions. Do not open or mutilate the battery. Disconnect the battery before shipping this product. For more details, see the Important Information section. Getting Started Installing Your Phone Charge the battery 1. Unpack all handsets, batteries, and battery covers. If you need to remove a battery cover, press in on the notch and slide the cover down. 2.
Connect the telephone cord Connect the TEL line jack to a standard telephone wall jack. Test the connection 1. Pick up the handset from the cradle and press Talk/flash. You should hear a dial tone, and the display should say Talk. xx If you don't hear a dial tone or the display says Check Tel Line, try checking the connection between the base and the phone jack. 2. Make a quick test call. (Press End to hang up.
Visit our website for more information on compatible models. xx If you are not certain of the profiles supported by your Bluetooth phone or if you have difficulty pairing your phone to the XDECT R035BT, see the manual that came with your phone. xx With the MobileLink feature, you can essentially treat your cellular phone as a second line. You can use the XDECT R035BT handset to make and receive calls on your cellular phone number, put cellular calls on hold, and transfer calls to other handsets.
xx Most cellular phones automatically transfer the audio to a Bluetooth device as soon as it pairs; if yours does not, look in your phone's Bluetooth setup for a "transfer audio" or "send audio to device" option. To test the connection 1. Pick up the handset from the cradle. 2. Dial the number you want to call, then press LINK twice on the handset. You may not hear a dial tone or ringing, but the handset display says Talk. 3. Make sure the call connects and you can hear clearly.
Installing the Repeater/Charger(s) (if included) Connect the repeater/charger power cord 1. If your phone came with any accessory handsets and chargers, connect a charger AC adapter to each charger's DC IN 9V jack and set the plug into the notch as shown. (These adapters might already be connected.) 2. Plug the other end of the adapter into a standard 240V AC power outlet. Attach the stand 3. To attach the stand, you have to decide if you want the repeater to rest on a desk or hang on a wall.
Using the Repeater How it works An XDECT R003BT repeater can extend the range of your base in all directions, including up and down. The XDECT R003BT repeater unit is also a charger for the accessory handset. Each handset will automatically connect to the repeater or the base, depending on which signal is stronger, and the handset operates exactly the same way whether it's connected to the base or to the repeater. The repeaters must be registered to the base before you can use them.
Repeaters can be up to 3 chain-links (maximum) from the base Example of coverage area with 6 repeaters (maximum total) You can roam anywhere within range of the base or the repeater(s) and make and receive calls as usual from your handsets. xx If you want to use the repeater with a new base, simply register the repeater to the new base (see page 37). The repeater overwrites its own link to the base.
Picking the best spot The best spot for the repeater is as far from the base as possible while still maintaining a good signal, or near the edge of the base’s coverage area. To find the edge of the coverage area: 1. Stand near the base and make a call on the handset. 2. While on the call, carry the handset away from the base towards the general area where you want to put the repeater. 3. Watch the signal strength icon on the handset. Make a note where the icon drops from 4 bars to 3 bars. 4.
Understanding Your Phone Parts of the base Antenna (not shown) BLUETOOTH CELLLINK MOBILELINK MESSAGE COUNTER Bluetooth DOWN UP ON/OFF DND Charging contacts FIND DO NOT DISTURB REV PLAY/ STOP DELETE FWD Base keys and how they work Key name (and icon) What it does FIND -- In standby: page all handsets to find a lost one. DO NOT DISTURB -- In standby: turn the Do Not Disturb feature on or off (see page 24). ON/OFF -- In standby: turn the answering system on or off.
Key name (and icon) What it does PLAY/STOP -- In standby: start playing messages. -- While a message is playing: stop playing messages. -- While the phone is ringing: mute the ringer for this call only. ( ) FWD ( ) DELETE ( ) DOWN (–) Up (+) Bluetooth MobileLink ( 10 ) -- While a message is playing: skip to the next message. -- While a message is playing: delete this message. -- In standby, delete all messages. -- While Bluetooth phone is ringing: reject the call.
Parts of the handset Visual ringer Earpiece Display MENU/ SELECT UP LINK CLEAR/ INTERCOM CID/RIGHT PHONEBOOK/ LEFT TALK/ FLASH END Twelvekey dial pad DOWN MESSAGES/ MUTE REDIAL/ PAUSE SPEAKER Charging contacts Microphone Handset keys and how they work Key name (and icon) Up ( ) CID/right ( ) What it does -- In standby: increase the ringer volume. -- During a call: increase the call volume. -- In the menu or any list: move the cursor up one line.
Key name (and icon) */ lock( Down ( -- In standby: press and hold to lock or unlock the keypad. ) ) Menu/select End ( ) Clear/intercom Phonebook/left ( Talk/flash ( Speaker ( 12 ) ) ) What it does -- In standby: decrease the ringer volume. -- During a call: decrease the call volume. -- In the menu or any list: move the cursor down one line. -- In standby: open the menu. -- In the menu or any list: select the highlighted item. -- During a call: hang up.
Key name (and icon) What it does Redial/pause Link ( ) Messages/mute ( ) -- In standby: open the redial list. -- While entering a phone number: insert a 2-second pause. -- In standby: start a telephone call using your paired Bluetooth phone. -- While the Bluetooth phone is ringing: answer the incoming call. -- During a MobileLink call: switch to a waiting call. (See page 3 for information on pairing your Bluetooth phone.) -- In standby: access your answering system.
Icon What it means T-coil mode is on (see page 34). The battery is 1) empty, 2) getting low, 3) half charged, or 4) fully charged. [Aa] [aA] The signal from the base is 1) weak, 2) low, 3) strong, or 4) very strong. The handset enters capital letters first (see page 16). The handset enters lower-case letters first (see page 16). There is a cellular phone paired to MobileLink slot #1, #2, or both.
xx xx If you open the menu during a call, use Phonebook/left to back out of the menu without hanging up. If you don't press any keys for 30 seconds, the handset exits the menu. The Handset Setup Menu You can change these settings separately for each handset. T-coil Ringer Tones Personal Ring Banner Key Touch Tone Turn on T-coil mode to reduce noise on some hearing aids (see page 34). You can set a different ring tone for the land line and each paired cellular phone.
the number keypad to enter 2 digits for the hour and 2 digits for the minutes, e.g., 0530 for 5:30). The Global Setup menu The settings on this menu affect all handsets and the base. Before changing these settings, make sure the phone is in standby and all handsets are within range of the base. (Only one handset at a time can change these settings.) Set Line Mode Insert 0 VMWI Reset Do not change this setting unless instructed to by customer service.
Using Your Phone You can control the features in this section through the handset. Learning the Basics To... From the land line From the cell phone make a call: Dial the number, then Press Talk/flash or Speaker Press Link twice.* answer a call Press Talk/flash or Speaker. Press Link. hang up mute the microphone during a call put a call on hold return to a call on hold switch from one line to the other (automatic hold) Press End or put the handset in the cradle. Press Messages/mute.
Change the volume Speaker and earpiece volume Ringer volume -- You can change the volume of the speaker on the base and each cordless handset separately. -- You can change the volume of the earpiece on each handset; this does not affect the handset’s speaker volume. -- Anytime you are listening to a speaker or earpiece, press Up to increase the volume and Down to decrease it. -- You can change volume of the ringer on the base and each handset separately.
For New Zealand Model: Press TALK/FLASH on the handset to accept the waiting call. The first caller is put on hold, and you will hear the new caller after a short pause. To return to the original caller, press TALK/FLASH again. For Mobile Phone Calls: When you receive a call waiting call while on a mobile phone call press LINK to switch between mobile phone calls (for calls to the same mobile phone only).
To… Follow these steps… Open the CID list Open the Redial list Press CID/right. Press Redial/pause. Press Down to scroll through the list from newest to oldest. Press Up to scroll from oldest to newest. Highlight the number you want and press Talk/flash (or Link twice*). Press Phonebook/left. Scroll through the list Dial a number Close the list * If you have two cellular phones paired, the phone prompts you to choose one. Select the phone you want, press MENU/SELECT, and press Link again.
To do this... Do this... Open/close the phonebook Scroll through the entries Jump to entries that start with a certain letter Press Phonebook/left. Dial an entry Press Down to scroll through the phonebook from A to Z or Up to scroll from Z to A. Press the number key corresponding to the letter you want to jump to. Find the entry you want to dial, and press Talk/flash (or Link twice*). * If you have two cellular phones paired, the phone prompts you to choose one.
Finding a Lost Handset With the phone in standby, press Find on the base. All the handsets will beep for 1 minute; to end the page, press Find again or press any key on any handset. Using Multi-Handset Features To use the features in this section, you must have at least two cordless handsets. Expanding your phone xx xx xx xx xx Your base supports a total of six cordless handsets: the one that came with the base and up to five XDECT R003BT accessory handsets.
As long you have privacy mode on, no other handsets can interrupt your call. To allow another handset to join the call, press Menu/select twice to turn privacy mode off. Call transfer Using MobileLink To… On the land line transfer a call Press Clear/intercom, then select the handset you want to transfer the call to (select All to page all the handsets). When the other handset accepts the call, you’ll be disconnected.
To... make an intercom page cancel a page answer an intercom page leave an intercom call answer an outside call during an intercom call Follow these steps: Press Clear/intercom, then select the handset you want to talk with (select All to page all handsets at the same time). Press End. Press Clear/intercom or Talk/flash. Press End. Press Talk/flash or Link (depending on which line is ringing). The phone automatically disconnects the intercom call and connects you to the outside line.
number. Press Menu/select to transmit the code. Or, if you change your mind, use Phonebook/left to close the phonebook. Voice message notification xx xx xx xx This feature supports Frequency-Shift Keying (FSK) message notification. Contact your voice mail provider for more details. If you subscribe to a voice mail service, your phone can notify you when you have a new message waiting.
Record Time Message Alert Call Screen Ans. On/off Set the amount of time callers have to leave a message, either 1 minute or 4 minutes. Choose Announce Only if you don’t want the system to let callers to leave a message. Have the system beep every 15 seconds when you have a new message; the beeping stops when you listen to all your new messages. (To mute the alert without listening to your messages, press any key on the base.
xx xx xx You can press the number key next to the commands instead of scrolling through them. If you don't press any keys for 30 seconds, the phone returns to standby. Only one handset can access the system at a time, and you can't access the system while another handset is on a land line or MobileLink call. Personalizing Your Greeting Your greeting can be between 2 seconds and 30 seconds long.
Getting Your Messages To… From the base From a handset (remote operation) Press Messages/ mute. play new messages The system announces the number of new and old messages, then plays each new message (followed by the time and date) in the order it was received. Within the first 2 seconds of a message, replay an earlier message press Rev. select 1:Repeat. Wait at least 5 Wait at least 3 seconds after seconds after restart the current the message starts, then press the message message Rev.
Screening Your Calls Another feature your answering system gives you is call screening. While the system is taking a message, you can hear the caller on the base speaker (if you turn on Call Screen) or from a handset. Only one handset at a time can screen calls. If another handset is screening the call, the handset beeps and returns to standby. To... hear the caller leaving a message answer the call mute the call screen without answering From the base Just listen to the caller over the speaker.
xx If your answering system is off, it will answer after about 15 rings and sound a series of beeps instead of your greeting. 2. During the greeting (or beeps), press # and immediately enter your security code. (If you enter it incorrectly 3 times, the system hangs up and returns to standby.) 3. The system announces the current time, the number of messages stored in memory, and a help prompt. Then it starts beeping intermittently to let you know it's waiting for your command. 4.
Important Information Solving Problems If you have any trouble with your phone, try these simple steps first. If you need help, visit the Customer Support page on our website; www. uniden.com.au for Australia or www.uniden.co.nz for New Zealand. If… Try… No handsets can make or receive calls. -- Checking the telephone cord connection. -- Disconnecting the base AC adapter. Wait a few minutes, then reconnect it. -- Making sure the base is plugged in.
If… Try… -- Making sure the Record Time is not set to Announce Only. The system won’t record -- Deleting messages (memory may be full). messages. -- Making sure the call was on the land line (the system cannot answer MobileLink calls). -- Seeing if another handset is using the A handset can’t access system. the answering system. -- Making sure the phone is in standby. -- Making sure your phone is in pairing mode.
If… Try… -- Re-registering the repeater. I can’t get my handset to switch to the repeater. -- Making sure the repeater and handset are registered to the same base. The LINK light on the repeater randomly starts blinking. -- Moving the repeater closer to the base. Weak or hard to hear audio If a caller’s voice sounds weak or soft, the signal might be blocked by large metal objects or walls; you might also be too far from the base, or the handset’s battery may be weak.
If static is on 1 handset or in If static is on all handsets or in all 1 location: locations: -- Check nearby for one of the common interference sources. -- Try moving the handset away from a suspected source, or try moving the suspected source so it’s not between the handset and the base. -- There is always more noise at the edges of the base’s range. If an Out of Range message displays, try moving closer to the base. -- Check near the base for the source of interference.
Liquid damage Moisture and liquid can damage your cordless phone. If the exterior housing of the handset or base is exposed to moisture or liquid, wipe off the liquid, and use as normal. If moisture or liquid is inside the plastic housing (i.e. liquid can be heard in the phone or liquid has entered the handset battery compartment or vent openings on the base), follow these steps: Handset Base -- Remove the battery cover and disconnect the battery.
Resetting and Registering Handsets If you are having trouble with a cordless handset or if you want to replace one, you need to clear the registration information from the base and the handset: Do you have the base the handset is registered to? Yes No 1. Press and hold END and # until the System Reset menu appears (about 5 seconds). 2. Select Deregister HS. The display lists all registered handsets. 3. Select the handset you want to reset. 4. When the handset asks you to confirm, select Yes.
In about 30 seconds, the handset display should say Registration Press TALK/FLASH makeup sure a dial tone. Complete Each of .these bases can and support toyou twoget DRX402 UltraRange chargers, including any that were supplied with If... Try... your phone. - you don’t hear a dial tone Making sure the handset is Usually, you can't tell when a handset between fullyswitches charged, then starting - the display says Registration Failed the base and the charger in the middle a call, over of at step 1.
- Only register one repeater at a time. If more than one repeater is in registration mode at the same time then they can interfere with each other. - Only register a repeater to one base at a time. If more than one base is in registration mode at the same time then you can't control which base the repeater registers to.
AC Adapter and Battery Information xx xx xx xx xx xx Use only the supplied AC adapters. Be sure to use the proper adapter for the base and any chargers. Do not place the power cord where it creates a trip hazard or where it could become chafed and create a fire or electrical hazard. Do not place the unit in direct sunlight or subject it to high temperatures. Fully charged, the battery should provide about 10 hours of talk time and about 7 days of standby time.
INDEX A Answering a Call....................17 Answering System.................25 B Base Unavailable...................36 Battery Install .........................1 Battery Information...............39 Bluetooth........................2, 3, 4 C Caller ID.................................19 Call Waiting...........................18 Conferencing.........................22 Controls & Parts of the Phone... .....................................9, 11 D Day and Time.........................
S Screening calls.................26, 29 Security Code..................25, 29 Speaker Volume........10, 11, 18 T T-coil .........................14, 15, 34 Talk and Standby Times . ......39 Transferring a Call................ 23 Troubleshooting....................31 V Voice Mail..............................25 Voice Message Waiting Indicator Reset ..........16, 25 W Wall Mount the Repeater/ Charger...............................
WARRANTY One-year limited warranty This product comes with a one year limited warranty. Please refer to our Uniden website for any details or warranty durations offered in addition to those contained below. UNIDEN XDECT R035BT IMPORTANT Evidence of the original purchase is required for warranty service.
Product and return it to you without charge for parts and service. This warranty does not provide for reimbursement or payment of incidental or consequential damages. This EXPRESS WARRANTY is in addition to and does not in any way affect your rights under the TRADE PRACTICES ACT 1974 (Cth) (Australia) or the CONSUMER GUARANTEES ACT (New Zealand).
©2010 Uniden Australia Pty Ltd/Uniden New Zealand Limited Printed in Vietnam UNZZ01156BZ(0)
