Note
When continuity testing has been completed, disconnect the connection between
the testing leads and the circuit under test.
Measurement Operation(11)
22
Model UT10A: OPERATING MANUAL
Testing for Continuity
To test for continuity, connect the Meter as below:
1. Set the rotary switch to Ω range.
2. Press SELECT button to select continuity test.
3. Connect the test leads across with the object being measured.
The buzzer sounds continuously if the resistance of a circuit under test is around
less than 70Ω.
The LCD displays the resistance value of a circuit under test simultaneous.
