Data Sheet

2
Rev. 2/21
Workman
®
HD Series Specifications*
* Specifications and design subject to change without notice. Products depicted in this literature are for demonstration purposes only.
Actual products offered for sale may vary in use, design, required attachments and safety features. See distributor for details on all warranties.
**At operator's ear; 3600 rpm with bed and sides installed.
The Workman HD utility vehicle is manufactured
in Tomah, WI ISO 9002 Certified Plant.
WORKMAN HDX, NO BED, MODEL 07383
WORKMAN HDX, W/BED, MODEL 07384
WORKMAN HDX - 4WD, MODEL 07386
WORKMAN HDX - 4WD, MODEL 07386TC
WORKMAN HDX - D MODEL 07385
WORKMAN HDX - D MODEL 07385TC
WORKMAN HDX - D - 4WD, MODEL 07387
WORKMAN HDX - D - 4WD, MODEL 07387TC
WORKMAN HD, MODEL 07369
ENGINE
Kubota
®
972 EFI, 32.5 hp (24.2 kW), 4-cycle, liquid-
cooled, 962 cc, 3-cylinder overheated camshaft,
counterbalanced gasoline engine. Governed maximum
of 32.5 hp at 3600 rpm. Rear engine location direct
coupled to a transaxle. 12-volt electric starter. Fuel
Injected is a closed loop system with oxygen sensor
to adjust air/fuel ratio and manifold pressure sensor
to adjust for altitude. Full pressure lubrication with
spin-on oil filter.
Kubota 902D, 3-cylinder, inline vertical, 4-cycle,liquid
cooled, counterbalanced diesel engine, 23.3 hp
(17.4 kw); governed to a maximum speed of 3600
rpm. 58.0 cu. in. (950 cc) displacement. Rear engine
location. Direct couple to transaxle. 12-volt electric
starter. Full pressure lubrication with spin-on oil filter.
Meets EPA Tier IV compliance. Biodiesel ready for use
up to B-20 (20% biodiesel and 80% petrol blend).
Kohler Model CH23, 2-cylinder, 4-cycle,
air-cooled engine. 23 hp (17.2 kW) at 3600
rpm governed to a maximum speed of 3600
rpm by an internal governor. 41.1 cu. in. (674
cc) displacement. Electronic ignition. Rear
engine location direct coupled to a transaxle.
12-volt electric starter. Full pressure
lubrication with spin-on oil filter. Meets all
EPA & CARB emission standards.
CLUTCH
7.5" (19 cm) clutch and pressure plate
INSTRUMENTATION
Fuel and coolant temperature gauges. Hour meter. Oil
pressure, check engine and battery charge indicator
lights. Tachometer and speedometer.
Fuel and coolant temperature gauges. Hour meter.
Oil pressure, glow plug and battery charge indicator
lights. Tachometer and speedometer.
Fuel gauge, hour meter, oil pressure warning
light and battery charge indicator light.
Tachometer / speedometer optional.
ALTERNATOR
60 amp with electronic regulator 25 amp with electronic regulator
TIRES
Front: 20” x 9” - 12, 6-ply rating, turf tread
Rear: 24” x 12” - 12, 6-ply rating, turf tread
COOLING SYSTEM
Aluminum radiator with 10 fins per inch dual pass. Right side mounted with removable screen for debris cleaning.
Thermal controlled DC electric fan.
Fan forced air.
AIR CLEANER
Remote mounted, heavy-duty 2-stage air cleaner with evacuator valve. Large capacity, dual element.
CLEARANCE CIRCLE 2WD
Inside = 32 in (81 cm); Outside = 194 in (493 cm)
CLEARANCE CIRCLE 4WD
Inside = 100 in (254 cm); Outside = 300 in (762 cm) N/A
FUEL CAPACITY
6 gallons (22.7 liters)
FUEL PUMP
12V internally regulated 42 psi in-tank Electronic pump Diaphragm pump
FUEL FILTER
In tank filter sock. 10 micron polyester depth.
Combination fuel filter / water separator with a 30
micron filtration and 50 mesh suction screen in tank.
In-line 40 micron filter and 50 mesh suction
screen in tank.
HORN
Standard, button on dash.
SOUND LEVEL
75 db(A)** 85 db(A)** 80 db(A)**
VEHICLE SHIPPING WEIGHT
Model 07383: 1623 lbs. (738 kg)
Model 07384: 1951 lbs. (887 kg)
Model 07386: 2010 lbs. (914 kg)
Model 07386TC: 2784 lbs. (1265 kg)
Model 07385: 1956 lbs (889 kg)
Model 07385TC: 2730 lbs (1240 kg)
Model 07387: 2015 lbs (916 kg)
Model 07387TC: 2789 lbs (1268 kg)
Model 07369: 1848 lbs. (840 kg)
VEHICLE ACTUAL
WEIGHT W/O FUEL
Model 07383: 1623 lbs. (738 kg)
Model 07384: 1951 lbs. (887 kg)
Model 07386: 2010 lbs. (914 kg)
Model 07386TC: 2091 lbs. (950 kg)
Model 07385: 1956 lbs (889 kg)
Model 07385TC: 2037 lbs (926 kg)
Model 07387: 2015 lbs (916 kg)
Model 07387TC: 2096 lbs (953 kg)
Model 07369: 1848 lbs. (840 kg)
TOTAL CAPACITY
Model 07384: 3249 lbs. (1477 kg)
Model 07386: 3190 lbs. (1450 kg)
Model 07386TC: 3109 lbs. (1413 kg)
Model 07385:3244 lbs. (1475 kg)
Model 07385TC:3163 lbs. (1438 kg)
Model 07387: 3185 lbs. (1448 kg)
Model 07387TC: 3104 lbs. (1411 kg)
Model 07369: 3352 lbs. (1524 kg)
CARGO BED CAPACITY W/200
LB. OPERATOR AND 200 LB.
PASSENGER
Model 07384: 2849 lbs. (1295 kg)
Model 07386: 2790 lbs. (1268 kg)
Model 07386TC: 2709 lbs. (1231 kg)
Model 07385: 2844 lbs.(1293 kg)
Model 07385TC: 2763 lbs. (1256 kg)
Model 07387: 2785 lbs. (1266 kg)
Model 07387TC: 2704 lbs. (1229 kg)
Model 07369: 2952 lbs. (1342 kg)
