Call your Toro distributor at 800-803-8676

FEATURES

Workman

HD Series

HEAVY-DUTY UTILITY VEHICLES

• Industry-leading hauling and towing capacity:

– 3,249 lb (1,477kg) total capacity – HDX

–

3,244 lb (1,475kg) total capacity – HDX-D

– 3,500 lb (1,587kg) towing – all models

• Electronic Fuel Injection Performance –

HDX Models

– Smooth, responsive driving

– Increased fuel economy over carbureted

engines

– Instant cold starting

– Automatic high altitude compensation

– On-board diagnostics

• Throttle-by-wire – HDX Models

– Electronic throttle control connects the

accelerator pedal to the throttle by wire

– Improved torque management

– Consistent speed control during

applications & in varying load

conditions

• Four-wheel hydraulic disk

brakes for easier stopping and

fast servicing

• Proven ride comfort

– Independent, double A-frame

front suspension with dual coil

springs and shock absorbers

provides 5.75” (14.6 cm) front travel

– DeDion rear axle with dual leaf

springs and shock absorbers provide

3” (7.6 cm) rear travel

• Extreme durability

– DeDion rear axle with I-beam design isolates

and protects transmission, engine and main

frame from vehicle loading

– Integrated wheel bearings provide enhanced

sealing and consistent heavy load carrying

capability

– Front bumper and front fenders designed to

withstand incidental impacts without damage

* With standard suspension configuration including installed bed.

Get more work done

every day with confidence.

The Workman® HD Series is designed with your toughest work challenges in mind, from

the front bumper to the rear bumper and everything in between. Design components like

an I-beam-shaped DeDion rear axle, a truss-like front space frame, integrated wheel

bearings and 4-wheel hydraulic disc brakes provide the highest total carrying capacity*

in the industry and make the Workman ready for the toughest challenges.

toro.com/hd

Summary of content (5 pages)

PAGE 1
Workman HD Series ® HE AV Y- D U T Y U T IL I T Y V EHI C L E S F E A T U R E S • I ndustry-leading hauling and towing capacity: – 3,249 lb (1,477kg) total capacity – HDX – 3,244 lb (1,475kg) total capacity – HDX-D – 3,500 lb (1,587kg) towing – all models • Electronic Fuel Injection Performance – HDX Models – Smooth, responsive driving – Increased fuel economy over carbureted engines – Instant cold starting Get more work done every day with confidence.
PAGE 2
Workman HD Series Specifications* ® WORKMAN HDX, NO BED, MODEL 07383 WORKMAN HDX, W/BED, MODEL 07384 WORKMAN HDX - 4WD, MODEL 07386 WORKMAN HDX - 4WD, MODEL 07386TC WORKMAN HDX - D MODEL 07385 WORKMAN HDX - D MODEL 07385TC WORKMAN HDX - D - 4WD, MODEL 07387 WORKMAN HDX - D - 4WD, MODEL 07387TC WORKMAN HD, MODEL 07369 Kubota 972 EFI, 32.5 hp (24.2 kW), 4-cycle, liquidcooled, 962 cc, 3-cylinder overheated camshaft, counterbalanced gasoline engine. Governed maximum of 32.5 hp at 3600 rpm.
PAGE 3
Workman HD Series Specifications (continued) ® * SPECIFICATIONS COMMON TO WORKMAN HD SERIES VEHICLES FRONT SUSPENSION REAR SUSPENSION BATTERY TRANSMISSION 3RD GEAR HIGH LOCKOUT DIFFERENTIAL LOCK 4WD SYSTEM FRAME STEERING 2-POST ROPS BRAKES HYDRAULICS LIGHTS SEAT BELTS / SEATS Independent system with dual “A” frame control arms, dual coil springs and dual shock absorbers with anti-sway bar. Provides 5 3/4” travel.
PAGE 4
Workman HD Series Specifications (continued) ® * WORKMAN VEHICLE ACCESSORIES 8 gpm (30.3 liter) at 2000 psi hydraulic flow in a separate circuit to power certain attachments and accessories (standard on TC models). HIGH FLOW HYDRAULICS KIT Provides Note: Model 07369 cannot run High Flow Hydraulics Kit. 200 GALLON SPRAYER 200 gallon (757 liter) low profile tank sprayer with diaphragm pump and detatchable control box. Three-section, 18.5 ft (5.6 m) open boom system.
PAGE 5
Multi Pro WM – 200-Gallon Sprayer Specifications ® * SPRAYER SPECIFICATIONS SOLUTION TANK High-density, impact-resistant polyethylene with large 16” (41 cm) fill opening, tapered bottom and sump with drain. RATED CAPACITY 200 gallons (757 liters). SPRAY PUMP AGITATOR CONTROLS Hardi 364/10.0, 6-diaphragm positive displacement pump w/1” (2.5 cm) input shaft; input speed 0~540 rpm; Flow rate 45 gpm (170.3 lpm) @ 40 psi (540 rpm). 4, side- mounted jet agitation nozzles for full tank agitation.
