CONCEALED TANK SYSTEM INSTALLATION INSTRUCTIONS
— 7 —
1000mm
0
H
X
L=X-H
L(max.150mm)
1
3
2
2
3
1
2. Cut Pipe
· Measure and cut pipe according to your toilet.
· Make sure to measure the sub floor and finished floor measurements before cutting to have the
correct center.
· Once pipe is cut, remove any burrs.
3. Attach Pipe
· Apply grease before sliding on pipe.
· Install pipe then put on dust cap to prevent debris from entering the pipe.
