Instructions / Assembly

The step-by-step guidelines in the installation instructions are a general reference for installing a Swiss Madison Concealed Tank System.
Should there be any discrepancies, Swiss Madison cannot be held liable.
It is recommended to install all Swiss Madison products by hiring a licensed professional
— 3 —
CONCEALED TANK SYSTEM ROUGH DIMENSIONS
1. Read the complete instruction manual before beginning installation.
2. Confirm that your model will fit in intended location and plumbing fixtures are
located where legally required before beginning installation.
3. Not all drawings on this manual are drawn to scale. Please refer to the model chart.
4. Two people are recommended to install and move this product.
NOTE: Specialized tools may be necessary to install a Swiss Madison Concealed Tank.
SUGGESTED TOOLS AND MATERIALS
Flat FileDrill LevelTape MeasurePencilSaftey Goggles WrenchHacksaw Plumbers Grease
x
NPT
0
24 
18 
max - 5 
2 
3 
21 
28 
23 
39 
”
3 
