Product Literature

The P220G and P220GS Series provide a full family of plastic valves that can deliver the water to meet the
challenging needs of today’s courses. With precise pressure regulation these valves deliver the optimum pressure
and flow requirements to every sprinkler on the zone ensuring maximum uniformity of the water to the turf.
EZReg
®
Pressure Regulating System
Can be adjusted from 5-100 psi to deliver the optimum pressure
for every need.
Spike Guard
™
Solenoid
With its 20,000 volt lightning rating, it virtually eliminates the need
for solenoid replacements in high lightning environments.
Internal Manual Bleed
Ensures the optimum pressure of the system even when being
operated manually.
Double-beaded Fabric Reinforced Diaphragm
Provides superior performance and extended life without tearing
in high-pressure golf applications.
P220G AND P220GS SERIES VALVES
FEATURES & BENEFITS
P220G-27-06
1½”
P220G-27-08
2”
P220G-27-04
1”
Self Cleaning Metering Pin
A self-cleaning feature that operates two
times during every valve cycle ensuring
smooth positive opening and closing.
Additional Features
Glass-filled nylon and stainless steel construction
Internal and External bleed
No external tubing
Standard, built-in Schrader-type valve for downstream
pressure verification
Flow control independent of solenoid
Self-aligning bonnet to ensure correct installation
Self-cleaning, stainless steel metering rod
Low-flow capability down to 5 gpm
Low-power requirement for longer wire runs
